Delta VFD25AMS43AFSHA

Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-04-1
04 Multi-stage Speed Parameters  This parameter can be set during operation.

1
st
Stage Speed Frequency

2
nd
Stage Speed Frequency

3
rd
Stage Speed Frequency

4
th
Stage Speed Frequency

5
th
Stage Speed Frequency

6
th
Stage Speed Frequency

7
th
Stage Speed Frequency

8
th
Stage Speed Frequency

9
th
Stage Speed Frequency

10
th
Stage Speed Frequency

11
th
Stage Speed Frequency

12
th
Stage Speed Frequency

13
th
Stage Speed Frequency

14
th
Stage Speed Frequency

15
th
Stage Speed Frequency
Factory Setting: 0.0
Settings 0.0~1500.0 Hz
 The multi-function input terminals (refer to setting 1~4 of Pr. 02-01~02-07 Multi-function input
command) are used to select multi-stage speed command (max. is 15
th
stage speed). The
multi-stage speed (frequency) is set by Pr. 04-00 to 04-14
as shown in the following diagram.
 The run / stop command can be controlled by the external terminal / digital keypad /
communication via Pr. 00-21.
 Each multi-stage speed can be set within 0.0~1500.0 Hz during operation.
 Explanation for the timing diagram of multi-stage speed and external terminals
The related parameter settings are:
1. Pr. 04-00~04-14: setting 1
st
~15
th
multi-stage speed (to set the frequency of each stage speed)
2. Pr. 02-01~02-07: setting multi-function input terminals (multi-stage speed command 1~4)
 Related parameters:
 01-22 JOG frequency setting
 02-01 multi-function input command 1 (MI1)
 02-02 multi-function input command 2 (MI2)
 02-03 multi-function input command 3 (MI3)
 02-04 multi-function input command 4 (MI4)
