Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-14-3
54: Communication error (CE1)
55: Communication error (CE2)
56: Communication error (CE3)
57: Communication error (CE4)
58: Communication time-out (CE10)
61: Y-connection /
△
-connection switch error (ydc)
62: Decel. energy backup error (dEb)
72: Channel 1 (S1~DCM) safety loop error (STL1)
76: Safe torque off (STo)
77: Channel 2 (S2~DCM) safety loop error (STL2)
78: Internal loop error (STL3)
79: U phase over current before run (Aoc)
80: V phase over current before run (boc)
81: W phase over current before run (coc)
82: U phase output phase loss (oPL1)
83: V phase output phase loss (oPL2)
84: W phase output phase loss (oPL3)
87: Drive over load in low frequency (oL3)
101: CANopen software disconnect 1 (CGdE)
102: CANopen software disconnect 2 (CHbE)
104: CANopen hardware disconnect (CbFE)
105: CANopen index setting error (CIdE)
106: CANopen station number setting error (CAdE)
107: CANopen memory error (CFrE)
121: Internal communication error (CP20)
123: Internal communication error (CP22)
124: Internal communication error (CP30)
126: Internal communication error (CP32)
127: Software version error (CP33)
128: Over-torque 3 (ot3)
129: Over-torque 4 (ot4)
134: Electronics thermal relay 3 protection (EoL3)
135: Electronics thermal relay 4 protection (EoL4)
140: GFF detected when power on (Hd6)
141: GFF occurs before run (b4GFF)
145: Model identification error (MErr)
As long as the fault is forced to stop, it will be recorded.
Low voltage (Lv) when stopped (LvS warning, no record). Low voltage (Lv) when operation (LvA,
Lvd, Lvn error, it will be recorded).
When dEb function is effective and enable, drive will start the dEb function and also record the
error code 62 to Pr. 06-17~06-22, Pr. 14-70~14-73 at same time.
