Delta VFD25AMS43AFSHA

Chapter 15 CANopen OverviewMS300 (High Speed Model)
15-22
Setting
*
Display
Fault
code
Description
CANopen
fault register
(bit 0~7)
CANopen
fault code
10
ovS
Ov at stop
Fault
000AH
Over-voltage at stop. Hardware failure in
current detection
2 3210H
11
LvA
Lv at accel
Fault
000BH
DC BUS voltage is less than Pr.06.00
during acceleration.
2 3220H
12
Lvd
Lv at decel
Fault
000CH
DC BUS voltage is less than Pr.06.00
during deceleration.
2 3220H
13
Lvn
Lv at normal SPD
Fault
000DH
DC BUS voltage is less than Pr.06.00 in
constant speed.
2 3220H
14
LvS
Lv at stop
Fault
000EH
DC BUS voltage is less than Pr.06-00 at
stop
2 3220H
15
OrP
Phase Lacked
Fault
000FH Phase Loss Protection 2 3130H
16
oH1
IGBT over heat
Fault
0010H
IGBT overheat
IGBT temperature exceeds protection
level.
3 4310H
18
tH1o
Thermo 1 open
Fault
0012H
IGBT over-heat protection error
3 FF00H
21
oL
Inverter oL
Fault
0015H
Overload. The AC motor drive detects
excessive drive output current.
1 2310H
22
EoL2
Thermal relay 2
Fault
EoL1
Thermal relay 1
Fault
0016H Electronics thermal relay 1 protection 1 2310H
23
EoL2
Thermal relay 2
Fault
0017H Electronics thermal relay 2 protection 1 2310H
