Chapter 11 Summary of Parameter SettingsME300
11-32
Pr. Explanation Settings Default
08-22 Wake-up delay time 0.00–600.00 sec. 0.00
08-23 PID control flag
bit 0 = 1: PID running in reverse follows the setting for
Pr.00-23.
bit 0 = 0: PID running in reverse refers to PID calculated
value.
bit 1 = 1: PID Kp gain is 2 decimal places.
bit 1 = 0: PID Kp gain is 1 decimal place.
2
08-26
PID output command limit
(reverse limit)
0.0–100.0% 100.0
08-27
PID command
acceleration / deceleration
time
0.00–655.35 sec. 0.00
08-61
Feedback of PID physical
quantity value
1.0–99.9 99.9
08-62
Treatment of the
erroneous PID feedback
level
0: Warn and keep operating (no treatment)
1: Fault and coast to stop
2: Fault and ramp to stop
3: Ramp to stop and restart after time set at Pr.08-63
(Without displaying fault and warning)
4: Ramp to stop and restart after time set at Pr.08-63.
The number of times of restart depends on the setting
for Pr.08-64.
0
08-63
Delay time for restart of
erroneous PID deviation
level
1–9999 sec 60
08-64
Number of times of restart
after PID error
0–1000 times 0
