Chapter 12 Description of Parameter SettingsME300
12.1-05-6
Rated Speed for a Permanent Magnet Synchronous Motor
Default: 2000
Settings 0–65535 rpm
Number of Poles for a Permanent Magnet Synchronous Motor
Default: 10
Settings 0–65535
Stator Resistance for a Permanent Magnet Synchronous Motor
Default: 0.000
Settings
0.000–65.535 Ω
Permanent Magnet Synchronous Motor Ld
Default: 0.00
Settings 0.00–655.35 mH
Permanent Magnet Synchronous Motor Lq
Default: 0.00
Settings 0.00–655.35 mH
Ke parameter for a Permanent Magnet Synchronous Motor
Unit: V / 1000 rpm
Default: 0
Settings 0–65535
