Chapter 12 Description of Parameter SettingsME300

12.1-13-3

 Group setting 05: Conveyor

The following table lists the relevant conveyor setting application parameters.

Pr. Explanation Settings

00-11 Speed control mode 0 (VF)

00-16 Load selection 0 (Normal load)

00-20 Master frequency command source (AUTO) 2 (External analog input)

00-21 Operation command source (AUTO) 1 (External terminals)

01-00 Motor 1 maximum operation frequency Default setting

01-01 Motor 1 output frequency Default setting

01-02 Motor 1 output voltage Default setting

01-03 Motor 1 mid-point frequency 1 Default setting

01-04 Motor 1 mid-point voltage 1 Default setting

01-05 Motor 1 mid-point frequency 2 Default setting

01-06 Motor 1 mid-point voltage 2 Default setting

01-07 Motor 1 minimum output frequency Default setting

01-08 Motor 1 minimum output voltage of motor 1 Default setting

01-12 Acceleration time 1 10 (s)

01-13 Deceleration time 1 10 (s)

 Group setting 07: Packing

The following table lists the relevant packing setting application parameters.

Pr. Explanation Settings

00-11 Speed control mode 0 (VF)

00-20 Master frequency command source (AUTO) 0 (Digital keypad)

00-21 Operation command source (AUTO) 2 (RS-485 Communication input)

02-00 Two-wire / Three-wire operation control

1 (two-wire mode 1, power on for

operation control (M1: FWD /

STOP, M2: REV / STOP))
