Chapter 11 Summary of Parameter SettingsMS300 (High Speed Model)
11-15
Pr. Explanation Settings
Factory
Setting
10: ACI
20: CANopen analog output
21: RS-485 analog output
22: Communication card analog output
23: Constant voltage output

03-21 Gain of analog output (AFM) 0~500.0 % 100.0

03-22
Analog output when in REV
direction (AFM)
0: Absolute value of output voltage
1: Reverse output 0 V; Positive output 0-10 V
2: Reverse output 5-0 V; Positive output 5-10 V
0

03-27 AFM output bias -100.00~100.00 % 0.00

03-28 AVI terminal input selection
0: 0~10 V
3: -10 V ~ +10 V (Pr. 03-69 ~ 03-74 is valid)
0

03-29
ACI terminal input selection
0: 4~20 mA
1: 0~10 V
2: 0~20 mA
0

03-30
Status of PLC
analog output
terminal
Monitor the status of PLC analog output terminals
bit 1: AFM
bit 2: AO10
bit 3: AO11
.
Read
only

03-31
AFM output selection
0: 0~10 V output
1: 0~20 mA output
2: 4~20 mA output
0

03-32 AFM DC output setting level 0.00~100.00 % 0.00

03-35
AFM filter output time 0.00 ~ 20.00 sec. 0.01

03-39 VR input selection
0：Disable
1：Frequency command
1

03-40 VR input bias -100.0~100.0 % 0.0

03-41 VR positive / negative bias
0: No bias
1: Lower than or equal to bias
2: Greater than or equal to bias
3: The absolute value of the bias voltage while
serving as the center
4: Serve bias as the center
0

03-42 VR gain
-500.0~500.0 % 100.0

03-43 VR filter time 0~2.00 sec. 0.01

03-44
Multi-function MO output by source
of AI level
0: AVI
1: ACI
0

03-45 AI upper level 1
-100 % ~100.00 % 50
