Chapter 11 Summary of Parameter SettingsMS300 (High Speed Model)
11-21
Pr. Explanation Settings
Factory
Setting
06-10
Over-torque detection level
(motor 2)
10~250 % (100 % corresponds to the rated current
of the drive)
120
06-11
Over-torque detection time
(motor 2)
0.0~60.0 sec.
0.1
06-13
Electronic thermal relay selection 1
(motor 1)
0: Inverter motor (with external forced cooling)
1: Standard motor (motor with fan on the shaft)
2: Disabled
2
06-14
Electronic thermal relay action time
1 (motor 1)
30.0~600.0 sec. 60.0
06-15
Temperature level over-heat (OH)
warning
0.0~110.0
o
C 105.0
06-16
Stall prevention limit level
0~100 % (Pr. 06-03, Pr. 06-04) 100
06-17 Fault record 1 0: No fault record 0
06-18 Fault record 2 1: Over-current during acceleration (ocA) 0
06-19 Fault record 3 2: Over-current during deceleration (ocd) 0
06-20 Fault record 4 3: Over-current during constant speed (ocn) 0
06-21 Fault record 5
4: Ground fault (GFF)
0
06-22 Fault record 6
6: Over-current at stop (ocS)
0
Fault record 7 (14-70) 7: Over-voltage during acceleration (ovA)
Fault record 8 (14-71) 8: Over-voltage during deceleration (ovd)
Fault record 9 (14-72) 9: Over-voltage during constant speed (ovn)
Fault record 10 (14-73) 10: Over-voltage at stop (ovS)
11: Low-voltage during acceleration (LvA)
12: Low-voltage during deceleration (Lvd)
13: Low-voltage during constant speed (Lvn)
14: Low-voltage at stop (LvS)
15: Phase loss protection (OrP)
16: IGBT over-heat (oH1)
18: TH1 open: IGBT over-heat protection error
( tH1o)
21: Drive over-load (oL)
22: Electronics thermal relay protection 1 (EoL1)
23: Electronics thermal relay protection 2 (EoL2)
24: Motor PTC overheat (oH3)
26: Over-torque 1 (ot1)
27: Over-torque 2 (ot2)
28: Low current (uC)
31: Memory read-out error (cF2)
33: U-phase current detection error (cd1)
34: V-phase current detection error (cd2)
