Chapter 11 Summary of Parameter SettingsMS300 (High Speed Model)
11-36
Pr. Explanation Settings
Factory
Setting
14-69 IGBT temperature at malfunction 6 -3276.7~3276.7
o
C
Read
only
14-70 Fault record 7 Refer to fault record Pr. 06-17~06-22 0
14-71 Fault record 8 Refer to fault record Pr. 06-17~06-22 0
14-72 Fault record 9 Refer to fault record Pr. 06-17~06-22 0
14-73 Fault record 10 Refer to fault record Pr. 06-17~06-22 0
14-74
Over-torque detection selection
(motor 3)
0: No function
1: Continue operation after Over-torque detection
during constant speed operation
2: Stop after Over-torque detection during constant
speed operation
3: Continue operation after Over-torque detection
during RUN
4: Stop after Over-torque detection during RUN
0
14-75 Over-torque detection level (motor 3)
10~250 % (100 % corresponds to the rated current
of the drive)
120
14-76 Over-torque detection time (motor 3)
0.0~60.0 sec.
0.1
14-77
Over-torque detection selection
(motor)
0: No function
1: Continue operation after Over-torque detection
during constant speed operation
2: Stop after Over-torque detection during constant
speed operation
3: Continue operation after Over-torque detection
during RUN
4: Stop after Over-torque detection during RUN
0
14-78 Over-torque detection level (motor 4)
10~250 % (100 % corresponds to the rated current
of the drive)
120
14-79 Over-torque detection time (motor 4)
0.0~60.0 sec.
0.1
14-80
Electronic thermal relay selection 3
(motor 3)
0: Inverter motor (with external forced cooling)
1: Standard motor (motor with fan on the shaft)
2: Disabled
2
14-81
Electronic thermal relay action time 3
(motor 3)
30.0~600.0 sec. 60.0
14-82
Electronic thermal relay selection 4
(motor 4)
0: Inverter motor (with external forced cooling)
1: Standard motor (motor with fan on the shaft)
2: Disabled
2
14-83
Electronic thermal relay action time 4
(motor 4)
30.0~600.0 sec.
60.0
