Chapter 8 Optional Cards MS300 (High Speed Model)
8-11
LED Indicator & Troubleshooting
LED Indicators
LED Status Indication Processing Methods
POWER Green On Power supply in normal status No action is required
POWER Green Off No power supply Check the power supply
LINK Green
On
Network connection in normal
status
No action is required
Flashes Network in operation No action is required
Off Network not connected
Check if the network cable is
connected
Troubleshooting
Abnormality Cause Processing Methods
POWER LED off
AC motor drive not powered
Check if AC motor drive is powered, and if the power
supply is normal.
CMM-MOD01 not connected to
AC motor drive
Make sure CMM-MOD01C is connected to AC motor
drive.
LINK LED off
Not connected to network
Make sure the network cable is correctly connected to
network.
Poor contact to RJ-45
connector
Make sure RJ-45 connector is connected to EtherNet
port.
No module found
CMM-MOD01 not connected to
network
Make sure CMM-MOD01 is connected to the network.
PC and CMM-MOD01 in
different networks and blocked
by network firewall.
Search by IP or set up relevant settings via the AC
motor drive keypad.
Fail to open
CMM-MOD01
setup page
CMM-MOD01 not connected to
network
Make sure CMM-MOD01 is connected to the network.
Incorrect communication
setting in DCISoft
Make sure the communication setting in DCISoft is set
to EtherNet.
PC and CMM-MOD01 in
different networks and blocked
by network firewall.
Conduct the setup via the AC motor drive keypad.
Able to open
CMM-MOD01
setup page but
fail to utilize
webpage
monitoring
Incorrect network setting in
CMM-MOD01
Check if the network setting for CMM-MOD01 is correct.
For the Intranet setting in your company, please consult
your IT staff. For the Internet setting at home, please
refer to the network setting instruction provided by your
ISP.
Fail to send
e-mail
Incorrect network setting in
CMM-MOD01
Check if the network setting for CMM-MOD01 is correct.
Incorrect mail server setting Please confirm the IP address for SMTP-Server.
