Chapter 8 Optional Cards MS300 (High Speed Model)
8-13
Environment
Noise immunity
ESD (IEC 61800-5-1, IEC 6100-4-2)
EFT (IEC 61800-5-1, IEC 6100-4-4)
Surge Test (IEC 61800-5-1, IEC 6100-4-5)
Conducted Susceptibility Test (IEC 61800-5-1, IEC 6100-4-6)
Operation / Storage
Operation: -10ºC ~ 50ºC (temperature), 90% (humidity)
Storage: -25ºC ~ 70ºC (temperature), 95% (humidity)
Shock / Vibration resistance
International standards:
IEC 61131-2, IEC 68-2-6 (TEST Fc) / IEC 61131-2 & IEC 68-2-27(TEST Ea)
Connector pin assignment
PIN PIN name Definition
1
6
5
9
1 - Not defined
2 - Not defined
3 Rxd / Txd-P Sending / receiving data P(B)
4 - Not defined
5 DGND Data reference ground
6 VP Power voltage – positive
7 - Not defined
8 Rxd / Txd-N Sending / receiving data N(A)
9 - Not defined
LED Indicator & Troubleshooting
There are 2 LED indicators on
CMM-PD01：POWER LED and NET LED. POWER LED displays the
status of the working power. NET LED displays the connection status of the communication.
POWER LED
LED status Indication Processing Methods
Green light on Power supply in normal status. No action is required
Off No power
Check if the connection between CMM-PD01 and
AC motor drive is normal.
NET LED
LED status Indication Processing Methods
Green light on Normal status No action is required
Red light on
CMM-PD01 is not connected to
PROFIBUS DP bus.
Connect CMM-PD01 to PROFIBUS DP bus.
Red light
flashes
Invalid PROFIBUS communication
address
Set the PROFIBUS address of CMM-PD01 between
1 ~ 125 (decimal)
Orange light
flashes
CMM-PD01 fails to communicate
with AC motor drive.
Switch off the power and check whether CMM-PD01
is installed correctly and connected normally to the
AC motor drive.
