DEMA D6B Series User Manual

NO.5 Function List
16
P042
Jogging frequency
0.00-400.00 Hz
5.00
○
P043
S curve time
0.0-6500.0s
0.0
○
5.3 Functional parameters of input/output terminals
Function
code
Function name
Setting range and data content
Ex-factory
value
Alteration
P044
FOR(X1) function
0: Invalid 1: Run 2: Forward
3: Reverse 4: Stop
5: Forward/reverse
6: Inching 7: Inching forward
8: Inching reverse
9: External control timer I
10: External control timer II
11: Setting frequency is forced
to P003
12: Radiator or motor
overheating
13: Emergency stop 14: Reset
15-16:Reserve
17: Acceleration/deceleration
time selection I
18: Acceleration/deceleration
time selection II
19: Multi-segment speed I
20: Multi-segment speed II
21: Multi-segment speed III
22: High speed
23:Medium speed
24: Low speed 25: PID
allowed
26: Multi-segment speed IV
27: UP 28:DOWN
29: Draft allowed 30: Reserve
31:Pulse counter
32: Pulse counter resets
02
╳
P045
REV(X2) function
03
╳
P046
RST(X3) function
14
╳
P047
SPH(X4) function
22
╳
P048
SPM(X5) function
23
╳
P049
SPL(X6) function
24
╳
P050
Y1 output function
0: Invalid
1: Indication during running
2: Zero-speed indication
3:Fault indication
01
○
P051
Y2 output function
05
○
P052
Output function (KA and
KC are terminals)
00
○
