DEMA D6B Series User Manual

NO.6 Detailed Function Description
45
6.4 Functional parameter of analog quantity
P070
Setting range
Unit
Ex-factory value
Alteration
Input channel selection
for analog quantity
0-4
1
0
╳
There are two channels Al1 and Al2 and three modes to be selected for analog quantity
input:
[Channel 1] 0: 0-10V 1: 0-5V
[Channel 2] 2: 0-20mA/0-10V 3: 4-20mA/2-10V
[Overlying of channel 1 and channel 2] 4: Overlying of 0-10V and 4-20mA/2-10V
[Note] Current or voltage input can be selected by channel 2 through jumper J1
This parameter can be set to satisfy different analog input signals.
When P070=4, output frequency is equal to 1/2 (U/Umax+I/Imax) x50Hz, wherein:
U: analog quantity voltage
I: analog quantity current
Umax: Maximum analog quantity voltage
Imax: Maximum analog quantity current
P071
Setting range
Unit
Ex-factory value
Alteration
Filtering constant of
analog quantity
0-50
1
20
╳
Setting of this parameter is related to reaction speed of analog quantity; the larger the P071
is set, the slower the analog quantity makes response.
P072
Setting range
Unit
Ex-factory value
Alteration
High-end frequency
of analog quantity
0.00-400.00 Hz
0.01 Hz
50.00
╳
P073
0.00-400.00 Hz
0.01 Hz
0.00
╳
Low-end frequency
of analog quantity
P074
0-1
1
0
╳
Bias direction of
high-end frequency
P075
0-1
1
0
╳
Bias direction of
low-end frequency
