DEMA D6B Series User Manual

NO.6 Detailed Function Description
35
6.3 Functional parameter of input/output terminals
P044
Setting range
Unit
Ex-factory value
Alteration
X1 terminal function
00-32
1
02
╳
P045
03
X2 terminal function
P046
14
X3 terminal function
P047
22
X4 terminal function
P048
23
X5 terminal function
P049
24
X6 terminal function
01: RUN refers to running, and can form several control mode in combination with other
terminals.
02: FOR refers to forward rotating
03: REV refers to reverse rotating
04: STOP refers to stopping
05: FOR/REV refers to forward/reverse switching, which may also be enabled through
three-wire connection. Refer to the following text for details.
06: JOG refers to jog
07: Jog forward, with related parameters of P020 and P042.
08: Jog reverse, with related parameters of P020 and P042.
09: External control timer 1 start
10: External control timer 2 start
Upon contact closure, the timer is started to time. When time is over, multi-functional output
point will be actuated.
11: Set forced frequency switching as P003.
