DencoHappel MATRIX OP21C User Manual

MATRIX control panel Operating MATRIX control panel
PR-2011-0110-GB • Subject to modifications • R9-03-2016 75
Fans ➜ Max. volume flow
The maximum volume flow or the maximum volume flows in m³/h of the con-
nected air handling unit must be entered by selecting "supply air fan" or extract
air fan" in the submenu "max. volume flow". The volume flow control is also based
on these data. Refer to the technical documentation of the respective air handling
unit for the maximum volume flow.
Energy Recovery System submenu
You can select the following energy recovery systems in the "ERS" submenu:
Air damper system submenu
The following air damper types can be selected in the "air damper system" sub-
menu:
m³/h
m³/h
Supply-air fan
7500
Extract-air fan
Max. volume flow
Supply-air fan
Extract-air fan
7500
Value range: 0 to 65,000 m
3
/h
Adjustable steps: 10 m
3
/h
Factory setting: 1000 m
3
/h
ERS type
Energy recovery
Disabled
Value range: Disabled (factory setting)
Ecoflow 2-point
Ecoflow 3-point
Ecostat
Ecoplat
Ecorot 0..10V
EcoplatTwin
Multiflow
Operating mode
Air damper system
Outside/outgoing-air
Display Type of damper
Value range: Disabled Disabled
Outside/outgoing-air damper
(Factory setting)
2-point damper
Manual 2-point 2-point damper
Manual 3-point 3-point damper
Air volume 3-point damper
