DencoHappel MATRIX OP21C User Manual

Operating MATRIX control panel MATRIX control panel
76 PR-2011-0110-GB • Subject to modifications • R9-03-2016
Electric heating submenu
The following types of electrical heating can be selected in the "Electric heating"
submenu (even if it is not configured for every MATRIX 4700 unit):
Service submenu
The refrigeration unit control can be set in the "direct evaporator" submenu:
Automatic 2-point 2-point damper
Autom.+fan 2-P. 2-point damper
Automatic 3-point 3-point damper
Autom.+fan 3-P. 2-point damper
Display Type of damper
NOTICE!
Notice: Description of the dampers control type, see "Submenu MA damper
mode" on page 65.
E-heating type
E heating
Disabled
Value range: Disabled
1-speed
2-speed
3-speed
0..10 V
2..10 V
0..10 V+1-speed
0..10 V+2-speed
0..10 V+3-speed
2..10 V+1-speed
2..10 V+2-speed
2..10 V+3-speed
Unit-related default settings are performed at the factory.
Type of refrigeration unit
DX evaporator
Disabled
Value range: Disabled (factory setting)
1-speed
2-speed
0..10 Volt
10..0 Volt
