MATRIX control panel Menu Structure OP5xx
PR-2011-0110-GB • Subject to modifications • R9-03-2016 91
1)
This menu is not available if MATRIX 4700 controls is used for standard and low-profile air handling units.
2)
This menu is only available if MATRIX 4700 controls is used with standard and low-profile air handling units.
Other menus (continued)
(→ 49)
Settings (continued)
(→ 57)
−
economy mode (→ 58)
−
Room temperature (→ 58)
−
Supply air temperature (→ 58)
−
Fan mode (→ 59)
−
OFF
Automatic
Auto (mute)
Speed xx %/stage x
−
Plant/unit (→ 59)
−
OFF
On
−
Fan speed (→ 60)
−
X %
−
Supply/extract-air duct pres-
sure (
→ 61)
−
x Pa
−
Supply/extract-air volume flow
(→ 61)
−
x m
3
/h
−
Controller mode (→ 62)
−
Heating only
Cooling only
Automatic
Passive Cooling
−
Room air flow
(
→ 63)
−
Automatic
manual
−
Mixing-air damper pos.
1)
(
→ 63)
−
X %
−
Outside air volume flow
(→ 64)
−
X %
−
Outside air automatic (→ 64)
−
Recirculating/mixed-
air
−
Secondary-air louvre (→ 64)
−
X %
−
Adjust louvre angle (→ 64)
−
x °
−
Calibrate discharge (→ 65)
−
Tm, To, Po
−
Supply temp. Limits (→ 65)
−
In heating mode
In cooling mode
−
Mixing-air damper mode
(→ 65)
−
Manual
Air volume flow
Automatic
Autom.+fan
−
Air quality (→ 66)
−
Normal operation setpoint
economy mode setpoint
Quality
−
Air flushing (→ 67)
−
Enabled/disabled
−
Basic reduced temperature
(
→ 67)
−
Offset to setpoint in °C/°F
−
Minimum outside air rate
(
→ 68)
−
X %
−
Minimum fan speed stage
(
→ 68)
−
Enabled/disabled
−
Low-noise speed (→ 68)
−
X %
−
Calibration air throw depth
(→ 68)
−
Position 0-100%
−
Room air flow SWIRL (→ 69)
−
Graphical calibration
−
Reset to
factory settings
