Denon AVR-1311 - Rückseite

42
DEUTSCH
Rückseite
Lesen Sie die Erläuterungen auf der Seite, die in Klammern angegeben ist ( ).
q t
wer
yuioQ0Q1
q PRE OUT-Anschlüsse ·························································· (5, 28)
w Lautsprecheranschlüsse ····················································· (5, 28)
e DOCK CONTROL-Buchse ························································ (16)
r S-VIDEO Anschluss ································································· (16)
t COMPONENT VIDEO-Anschlüsse ···································· (13, 14)
y Wechselstromeingang (AC IN) ················································· (5)
u VIDEO Anschlüsse ····························································· (13, 14)
i HDMI-Anschlüsse ···································································· (12)
o Digitale Audioanschlüsse ················································· (13, 14)
Q0 Analoge Audioanschlüsse ················································ (14, 16)
Q1 UKW/MW-Antennenanschlüsse ············································ (16)
HINWEIS
Berühren Sie nicht die inneren Anschlusskontakte auf der Rückseite.
Elektrostatische Entladung könnte das Gerät beschädigen.
