11
11AVR-1404/484
80 NC
-
81 NC
-
82 49326 INTREQ I CS49326 INTREQ
83 74HC151 A0 O IC832 CONTROL
84 74HC151 A1 O IC832 CONTROL
85 REMOCON I REMOTE CONTROL SIGNAL INPUT
86 GND
-
87 GND
-
88 V
SS
-
89 V
DD
-
VDD BACK UP
90 NC
-
91 M62446 CE O M62446 CONTROL
92 PLL DATA O M62446/PLL CONTROL
93 PLL CLK O M62446/PLL CONTROL
94 PLL DT IN I PLL CONTROL
95 TU MUTE O TUNER MUTE
96 STEREO I STEREO DETECT
97 TUNED I TUNED DETECT
98 PLL CE O PLL CONTROL
99 SEL 2 O LA7952 CONTROL (VIDEO)
100 SEL 1 O LA7952 CONTROL (VIDEO)
Pin No. Pin Name I/O Function
