Denon AVR-1404 Service Manual

29
29AVR-1404/484
PARTS LIST OF P.W.B. UNIT
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model EU: U.S.A. model (AVR-484) E2: Europe model
E2A: Asia model E1C: China model EUT: Taiwan R.O.C. model
E1K: Korea model
MAIN P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 963 0110 507 IC MC7815CT *
IC102 963 0021 502 IC KIA7915PI
IC103 960 0159 501 IC KIA7805API
IC104 963 0110 604 IC MC7805CT *
IC105 960 0195 808 IC ICP-N15
IC701 960 0174 308 IC TC9273N-007
IC702,703 960 0179 701 IC NJM2068DD
Q104C 960 0196 506 Transistor KSC1845F
Q104FL,104FR 960 0196 506 Transistor KSC1845F
Q104SL,104SR 960 0196 506 Transistor KSC1845F
Q111-115 960 0196 904 Transistor DTC114YS
Q116 960 0196 409 Transistor 2SC1740SR
Q117 960 0196 904 Transistor DTC114YS
Q151 960 0196 409 Transistor 2SC1740SR
Q171 960 0005 202 Transistor KTC3198Y
Q171A-171C 960 0196 302 Transistor KTA1268BL
Q172-177 960 0005 202 Transistor KTC3198Y
Q178 960 0005 105 Transistor KTA1266Y
Q179 960 0189 005 Transistor KSA916Y
Q180,181 960 0196 302 Transistor KTA1268BL
D101-105 963 0096 508 Diode 1N4148
D121-126 963 0096 508 Diode 1N4148
D131A,131B 960 0197 107 Diode KBPC604
D132 963 0096 508 Diode 1N4148
D133,134 963 0046 202 Zener diode MTZJ18B
D135 963 0096 508 Diode 1N4148
D136 963 0058 504 Zener diode MTZJ11B
D137 963 0096 508 Diode 1N4148
D138 963 0058 407 Diode 1N4007
D141-146 963 0058 407 Diode 1N4007
D148 963 0096 508 Diode 1N4148
D149,150 963 0058 407 Diode 1N4007
D151 963 0096 508 Diode 1N4148
D152,153 963 0058 407 Diode 1N4007
D154 963 0047 405 Zener diode MTZJ7.5B
D157 963 0058 708 Zener diode MTZJ20B
D158-160 963 0096 508 Diode 1N4148
RESISTORS GROUP
R104C 963 9005 451 Metal oxide 5.6 kohm 1W (NB)
R104FL,104FR 963 9005 451 Metal oxide 5.6 kohm 1W (NB)
R104SL,104SR 963 9005 451 Metal oxide 5.6 kohm 1W (NB)
R105C 963 9005 451 Metal oxide 5.6 kohm 1W (NB)
R105FL,105FR 963 9005 451 Metal oxide 5.6 kohm 1W (NB)
R105SL,105SR 963 9005 451 Metal oxide 5.6 kohm 1W (NB)
