35
35AVR-1404/484
CNT P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401 963 0043 700 IC LC72131
IC402 963 0043 904 IC LA1266
IC403 963 0044 000 IC LA3401
IC601 960 0180 101 IC LA7952
IC602 963 0074 902 IC NJM7812FA
IC651,652 960 0180 101 IC LA7952
Q401 963 0099 301 Transistor KTC3880S
Q402 963 0079 305 Transistor DTA114YK
Q403,404 963 0058 203 Transistor DTA114EK
Q405,406 960 0196 603 Transistor KTC2874B
Q407 963 0079 305 Transistor DTC114YK
Q408 963 0058 203 Transistor DTA114EK
Q409 963 0099 301 Transistor KTC3880S for E2,E2A
Q551 960 0196 700 Transistor KTC3200BL
Q552 960 0196 302 Transistor KTA1268BL
Q553-555 963 0075 309 Transistor DTA114ES
Q601,602 960 0096 800 Transistor 2SC3199Y
Q603,604 960 0196 904 Transistor DTC114YS
Q605,606 963 0075 406 Transistor DTC114TS
Q651,652 960 0096 800 Transistor 2SC3199Y
Q653,654 960 0196 904 Transistor DTC114YS
Q655,656 960 0096 800 Transistor 2SC3199Y
Q657,658 960 0196 904 Transistor DTC114YS
D403 963 0096 605 Diode 1N4148WS (chip)
D404 963 0096 508 Diode 1N4148
D405,406 963 0096 605 Diode 1N4148WS (chip)
D551-561 963 0096 508 Diode 1N4148
D562,563 963 0058 407 Diode 1N4007
D564 960 0095 500 Zener diode MTZJ5.1B
D565 963 0096 508 Diode 1N4148
D601,602 963 0096 508 Diode 1N4148
D651,652 963 0096 508 Diode 1N4148
ZD341,342 960 0095 500 Zener diode MTZJ5.1B
ZD401 960 0095 500 Zener diode MTZJ5.1B
RESISTORS GROUP
R405 963 9005 545 Metal film 100 ohm 1/4W
R413 963 9005 558 Metal film 220 ohm 1/4W
R416 963 9005 561 Metal film 680 ohm 1/4W
R430 963 9005 545 Metal film 100 ohm 1/4W
R434 963 9005 545 Metal film 100 ohm 1/4W
R559 963 9005 642 Metal film 1.2 kohm 1W
R565 963 9005 642 Metal film 1.2 kohm 1W
R570 963 9005 642 Metal film 1.2 kohm 1W
R901,902 963 9005 574 Metal film 470 ohm 2W
VR401 960 0096 606 Semi fixed resistor 20 kohm
VR402 963 0056 205 Semi fixed resistor 50 kohm for E3,EU,E1C,EUT,E1K
VR402 960 0096 402 Semi fixed resistor 100 kohm for E2,E2A
To Next Page
