Denon AVR-1404 Service Manual

40
40AVR-1404/484
ZD335,336 960 0095 500 Zener diode MTZJ5.1B
LED301-304 960 0197 204 LED PI5-RD/HL50RDRF4T
LED306-309 960 0197 204 LED PI5-RD/HL50RDRF4T
RESISTORS GROUP
R231,232 963 9005 600 Metal film 100 ohm 1W
R271 963 9005 613 Metal film 220 ohm 1W
R274 963 9005 613 Metal film 220 ohm 1W
CAPACITORS GROUP
BC201 963 0061 504 Electric double layer 8200uF/5.5V
C201 963 9004 546 Ceramic 0.01uF/16V
C202 963 9004 711 Ceramic chip 0.1uF/50V
C203 963 9004 698 Ceramic chip 0.01uF/50V
C204 963 9005 914 Electrolytic 4.7uF/50V
C205 963 9004 711 Ceramic chip 0.1uF/50V
C206 963 9005 859 Electrolytic 47uF/16V for E2,E2A
C207 963 9004 546 Ceramic 0.01uF/16V for E2,E2A
C208 963 9004 614 Ceramic chip 270pF/50V for E2,E2A
C209 963 9005 778 Electrolytic 10uF/50V for E2,E2A
C210 963 9004 698 Ceramic chip 0.01uF/50V for E2,E2A
C211,212 963 9004 614 Ceramic chip 27pF/50V for E2,E2A
C213 963 9005 927 Electrolytic 0.1uF/50V
C214 960 9009 898 Electrolytic 1uF/50V
C219-226 963 9004 753 Ceramic chip 0.047uF/50V
C231 963 9005 875 Electrolytic 47uF/25V
C233 963 9005 875 Electrolytic 47uF/25V
C236 963 9005 875 Electrolytic 47uF/25V
C238 963 9005 875 Electrolytic 47uF/25V
C241-246 963 9004 753 Ceramic chip 0.047uF/50V
C251 963 9004 575 Ceramic chip 100pF/50V
C252 963 9004 643 Ceramic chip 47pF/50V
C253 963 9005 778 Electrolytic 10uF/50V
C261-263 963 9004 520 Ceramic 100pF/50V
C261L C261R 963 9004 575 Ceramic chip 100pF/50V
C262L,262R 963 9004 627 Ceramic chip 33pF/50V
C263L,263R 963 9005 778 Electrolytic 10uF/50V
C264-266 963 9004 520 Ceramic 100pF/50V for E1C,EUT,E1K
C267,268 963 9004 520 Ceramic 100pF/50V
C271 963 9005 859 Electrolytic 47uF/16V
C272 960 9009 898 Electrolytic 1uF/50V
C273 963 9005 859 Electrolytic 47uF/16V
C274 963 9006 227 Electrolytic 0.33uF/50V *
C275 963 9005 367 Ceramic chip 0.015uF/50V
C276,277 963 9006 214 Electrolytic 3.3uF/50V
C278 963 9006 227 Electrolytic 0.33uF/50V *
C279 963 9005 367 Ceramic chip 0.015uF/50V
C280,281 963 9005 370 Ceramic chip 8200pF/50V
C282 963 9004 575 Ceramic chip 100pF/50V
C285BL,285BR 963 9005 914 Electrolytic 4.7uF/50V
Ref. No. Part No. Part Name Remarks Q'ty New
