Denon AVR-1404 Service Manual

48
48AVR-1404/484
7 963 0093 514 Power button for black model 1
7 963 0108 904 Power button for silver model 1 *
7 963 0093 527 Power button for gold model 1
8 963 0094 801 3 key button (A) 2
9 963 0098 205 6 key button 1
10 963 0094 623 3 key button (B) for black model 2
10 963 0109 000 3 key button (B) for silver model 2 *
10 963 0109 013 3 key button (B) for gold model 2 *
11 963 0109 107 4 key button for black model 1 *
11 963 0109 110 4 key button for silver model 1 *
11 963 0094 720 4 key button for gold model 1
12 963 0109 204 RCA cover for E3,EU, black model 1 *
12 963 0109 217 RCA cover for E2, silver model 1 *
13 960 0191 417 LED lens 2
14 963 0092 900 Knob spring 1
15 963 0109 301 Main chassis 1
16 960 0183 904 Foot for black & gold model 4
16 963 0109 408 Foot for silver model 4 *
17 960 0184 107 Supporter bracket 1
18 960 0003 301 PWB supporter 2
19 963 0051 103 Card spacer 2
20 963 0109 505 FLT 16-ST-66GNK 1 *
21 960 0181 100 Remote sensor NJL64H380A 1
22 960 0197 204 LED PI5-RD/HL50RDRF4T 8
23 963 0095 208 Encoder EC16B24SA 3
24 - Heat sink 1
25 960 0184 204 Heat sink bracket B 1
26 960 0184 301 Heat sink bracket F 1
27 960 0090 107 Transistor 2SB1599Y Q102C,102FL,102FR,102SL,102SR 5
28 960 0090 000 Transistor 2SD2389Y Q101C,101FL,101FR,101SL,101SR 5
29 963 0058 106 Transistor 2SD947F Q103C,103FL,103FR,103SL,103SR 5
! 30 963 0109 602 Power trans for E3,EU,EUT 1 *
! 30 963 0109 615 Power trans for E2,E2A 1 *
! 30 963 0109 628 Power trans for E1C,E1K 1 *
31 960 0184 000 Screw bracket 4
! 32 963 0093 909 AC outlet for E3,EU,EUT 1
! 32 960 0143 203 AC outlet for E2,E2A 1
! 32 960 0144 202 AC outlet for E1K 1
33 960 0194 809 2P Terminal 1
34 963 0074 009 8P Terminal 1
35 960 0158 308 4P Terminal 1
36 963 0109 709 Back chassis for E3 1 *
36 963 0109 712 Back chassis for EU 1 *
36 963 0109 725 Back chassis for E2,E2A 1 *
36 963 0109 738 Back chassis for E1C 1 *
36 963 0109 741 Back chassis for EUT 1 *
36 963 0109 754 Back chassis for E1K 1 *
37 960 0192 403 AC cord stopper 1
! 38 963 0098 603 AC cord for E3,EU,EUT 1
! 38 963 0109 806 AC cord for E2,E2A 1 *
! 38 963 0109 819 AC cord for E1C 1 *
! 38 963 0098 700 AC cord for E1K 1
39 960 0176 209 Push switch for E3,EU 1
39 963 0098 807 Push switch for E2,E2A,E1C,EUT,E1K 1
40 963 0095 402 Headphone jack 1
54 963 0061 902 Fastener 1
Ref. No. Part No. Part Name Remarks Q'ty New
