16
AVR-1707/1507/687/587/487
NJW1197 Terminal Function
No. SYMBOL FUNCTION No. SYMBOL FUNCTION
1 ROUT Rch output 51 DCR_IN Multi-channel selector Rch input
2 COUT Cch output 52 DCR_OUT Input selector Rch output
3 LSOUT LSch output 53 GND Ground
4 RSOUT RSch output 54 DCL_IN Multi-channel selector Lch input
5 LBOUT LBch output 55 DCL_OUT Input selector Lch output
6 RBOUT RBch output 56 GND Ground
7 SWOUT SWch output 57 REC_B1R Input selector Rch REC output B1
8 GND Ground 58 REC_B1L Input selector Lch REC output B1
9 FIL_BL2 Lch Bass filter terminal 2 59 REC_A4R Input selector Rch REC output A4
10 FIL_BL1 Lch Bass filter terminal 1 60 REC_A4L Input selector Lch REC output A4
11 FIL_TL Lch Treble filter terminal 61 REC_A3R Input selector Rch REC output A3
12 TCAP Switching noise rejection capacitor 62 REC_A3L Input selector Lch REC output A3
13 FIL_BR2 Rch Bass filter terminal 2 63 REC_A2R Input selector Rch REC output A2
14 FIL_BR1 Rch Bass filter terminal 1 64 REC_A2L Input selector Lch REC output A2
15 FIL_TR Rch Treble filter terminal 65 REC_A1R Input selector Rch REC output A1
16 V+ + Power supply voltage input 66 REC_A1L Input selector Lch REC output A1
17 ADR Chip address select input 67 VDDOUT Internal Digital +Power Supply Output
18 V- - Power supply voltage input 68 DATA Control data signal input
19 L1IN Input selector Lch input 1 69 CLOCK Clock signal input
20 DCCAP_SW Switching noise rejection capacitor 70 LATCH Latch signal input
21 R1IN Input selector Rch input 1 71 MUTE External Mute control
22 DCCAP_RB Switching noise rejection capacitor 72 FL+ Input selector gain control Lch no-inverted output
23 L2IN Input selector Lch input 2 73 FL- Input selector gain control Lch inverted output
24 DCCAP_LB Switching noise rejection capacitor 74 FR+ Input selector gain control Rch no-inverted output
25 R2IN Input selector Rch input 2 75 FR- Input selector gain control Rch inverted output
26 DCCAP_RS Switching noise rejection capacitor 76 GND Ground
27 L3IN Input selector Lch input 3 77 LSCIN Multi-channel LSch input C
28 DCCAP_LS Switching noise rejection capacitor 78 RSCIN Multi-channel RSch input C
29 R3IN Input selector Rch input 3 79 LBCIN Multi-channel LBch input C
30 DCCAP_C Switching noise rejection capacitor 80 RBCIN Multi-channel RBch input C
31 L4IN Input selector Lch input 4 81 GND Ground
32 DCCAP_R Switching noise rejection capacitor 82 LAIN Multi-channel Lch input A
33 R4IN Input selector Rch input 4 83 RAIN Multi-channel Rch input A
34 DCCAP_L Switching noise rejection capacitor 84 CAIN Multi-channel Cch input A
35 L5IN Input selector Lch input 5 85 LSAIN Multi-channel LSch input A
36 GND Ground 86 RSAIN Multi-channel RSch input A
37 R5IN Input selector Rch input 5 87 LBAIN Multi-channel LBch input A
38 GND Ground 88 RBAIN Multi-channel RBch input A
39 L6IN Input selector Lch input 6 89 SWAIN Multi-channel SWch input A
40 L9IN Input selector Lch input 9 90 GND Ground
41 R6IN Input selector Rch input 6 91 LBIN Multi-channel Lch input B
42 R9IN Input selector Rch input 9 92 RBIN Multi-channel Rch input B
43 L7IN Input selector Lch input 7 93 CBIN Multi-channel Cch input B
44 L10IN Input selector Lch input 10 94 LSBIN Multi-channel LSch input B
45 R7IN Input selector Rch input 7 95 RSBIN Multi-channel RSch input B
46 R10IN Input selector Rch input 10 96 LBBIN Multi-channel LBch input B
47 L8IN Input selector Lch input 8 97 RBBIN Multi-channel RBch input B
48 L11IN Input selector Lch input 11 98 SWBIN Multi-channel SWch input B
49 R8IN Input selector Rch input 8 99 GND Ground
50 R11IN Input selector Rch input 11 100 LOUT Lch output
To Next Page
