Denon AVR-1507 Service Manual

69
AVR-1707/1507/687/587/487
OTHERS PARTS GROUP
BD601-603 nsp 00D 963 0234 603 COIL,BEAD D340160800060S
CN601 nsp 00D 963 0086 301 CN.WAFER 18P L101100031810S
CN602 nsp 00D 963 0086 709 CN.WAFER 11P L101100031110S
CN603 nsp 00D 963 0097 303 CN.WAFER 15P L101100031510S
CN603 nsp 00D 963 0097 303 CN.WAFER 15P L101100031510S
CN604 nsp 00D 963 0086 505 CN.WAFER 7P L101100030710S
CN604 nsp 00D 963 0086 505 CN.WAFER 7P L101100030710S
CN610 nsp 00D 963 0086 505 CN.WAFER 7P L101100030710S
CN612 nsp 00D 963 0097 303 CN.WAFER 15P L101100031510S
CP605,606 nsp 00D 963 0097 507 CN.WAFER 15P L101100041510S
CP607-609 nsp 00D 963 0206 408 CN.WAFER 7P L101100040710S
CP611 nsp 00D 963 0097 507 CN.WAFER 15P L101100041510S
L601-604 00D 963 0294 300 COIL,INDUCTOR 22UH D330220001020
RLY601-608 00D 963 0218 302 RELAY BC3-6 24V 2A G680240202020F
X601 00D 963 0294 407 CRYSTAL 28.63636MHZ E80028R636010S
00D 963 0218 001 TER,RCA 2PIN G60122001000YS
00D 963 0146 209 TER,RCA 4PIN G602405B01000S
00D 963 0218 108 TER,RCA 3PIN G60630401000YS
00D 963 0146 306 TER,RCA 6PIN G603603B2600YS
Ref. No. nsp Part Name Remarks Q'ty New

Denon AVR-1507 Specifications

General

Digital Inputs	2 Optical, 1 Coaxial
Analog Inputs	5
Tuner	AM/FM
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Sensitivity	200 mV
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
Input Impedance	47 kOhm
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
DSP Presets	5-channel stereo, Cinema EQ
