Denon AVR-1610 Service Manual

127
AVR-1910/1620/1610/790/590
12A nsp LABEL EAN 790EA 5507000002680S 2*
12A nsp LABEL EAN 590EA
5507000002380S 2*
13 nsp LABEL CONTROL
5500014920010S 2*
14 nsp PE SHEET
6327040059000S 1
15 324010001003D MIC CONDENSER
M040000310040S 1
16 nsp LABEL LICENSE 1910/790E3, 790EA
5507000002170S 1
16 nsp LABEL LICENCE 1910E2,E1C
5507000002300S 1
17 nsp PAD BOX BACK
6240210730000S 1*
18 nsp CARD WARRANTY E3
5727000003000S 1
18 nsp CARD WARRANTY E1C
5777001670010S 1
19 90M-ZC000600R CORD ASSY E2
L068250100020S 1
19 963611001490S CORD ASSY EA
L068250100070S 1
20 00D5139111030 LABEL COLOR SP
5507020170680S 1
21 nsp LABEL CARTON 1910E1C
5507003030380S 1*
21 nsp LABEL CARTON 1610E1C
5507003030360S 1*
21 nsp LABEL CARTON 1620E1C
5507003030370S 1*
22 nsp BUSHING TERMINAL E2, E1C, EA
2410040353010S 18
23 nsp LABEL DATE E1C
5507000000850S 1
25 nsp POLY BAG ACCESSORY
6330210222000S 1
26 nsp PAD CUSHION BOTTOM
6240210744000S 1*
27 nsp PAD MANUAL E2
6240210780000S 1*
28 nsp LABEL SERIAL NO.
5507002000070S 1
29 nsp LABEL PRODUCTION BOX E1C
5507100500970S 1
30 nsp CRoHS LABEL SET E1C
5507000000830S 1
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
