Denon AVR-1610 Service Manual

24
AVR-1910/1620/1610/790/590
Input S
Input CVBS
-5V：
OK
Check surrounding circuitry
soldering of VIDEO buffer.
OK
Check output of VIDEO buffer
(IC1904B) and surrounding
circuitry soldering.
Output V：
IC1901 33pin
Input V：
IC1901 3pin
OK OK
Check input selector and
surrounding circuitry soldering.
Output V：
IC1906 3pin
Check output of VIDEO buffer. NG Check input of VIDEO buffer. NG
Check output of input selector. NG
C
Input
CVBS/S
CN1018 3pin
4094_PWR(+5V)：
+5V：
Check connection of
iPod Doc.
To troubleshooting 1.1
Power not turn on.
CN1018 4pin
NG
Check V±5V，4094_PWR(+5V)
CN1018 1pin
Check cable between main unit
and monitor or check monitor.

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
