Denon AVR-1610 Service Manual

28
AVR-1910/1620/1610/790/590
Check the TV
Is the TV HDCP-compatible?
NO
Use an HDCP-compatible TV.
PC TVs cannot be used.
YES
Is the TV compatible with resolutions of 1080P?
NO
If the TV is not compatible with
resolutions of 1080P, no picture
will be output, even if the DVD
player's resolution is set to
1080P.
YES
Is the TV's input set to HDMI?
NO
Check the TV's input setting,
referring to the TV's operating
instructions.
YES
Are the picture and sound output when a different TV is used?
NO
The TV is defective.
YES
Check the set (AVR-4310CI)
Is the set's input set to HDMI?
NO
Check the set's input setting,
referring to the set's operating
instructions.
YES YES
The set does not recognize the TV.
Is the TV information properly displayed on the "Monitor info." display
menu?
Is IC5 pin 3 "H" (3V-5V)? With the TV connected, check the voltage of
the IC on the side on which the TV is connected.
NO
The pattern and circuit from
the HDMI connector (JACK5)
to the IC (IC5) is defective, or
the HDMI output circuitry is
defective.
(IC5/IC31 and surrounding
circuitry)
YES
When using a DENON DVD
player, is the fluorescent
display tube's "HDMI" indicator
lit?
If using a non-DENON DVD
player, proceed to "NO".
NO
The DVD player does not
recognize the connection
with the set.
Is the HDMI connector (JACK1/
JACK2/JACK3/JACK4) pin 19
"H" (5V)? With the DVD player
connected, check the voltage
of the HDMI connector for the
input on the side on which the
DVD player is connected.
NO
The pattern and circuit from
the HDMI connector (JACK1/
JACK2/JACK3/JACK4) to the
IC1045 is defective.
YES YES
The HDMI output circuitry is defective.
(IC1/IC31/IC5 and surrounding circuitry)

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
