41
AVR-1910/1620/1610/790/590
22 P80 DYN_GRN_LE
D
O C - - - - Z - O/L O/L O/L H : ON DYNAMIC EQ indicator
(green led) control
23 P77 DYN_RED_LED O C - - - - Z - O/L O/L O/L H : ON DYNAMIC EQ indicator (red led)
control
24 P76 ISELA I - - - - Eu Z - - O/L O/L SOURCE encoder operation
detect
25 P75 ISELB O C - - - - Z - O/L O/L O/L SOURCE encoder operation
detect
26 P74 VSELA O C - - - - Z - O/L O/L O/L VOLUME encoder operation
detect
27 P73 VSELB I - - - - Eu Z - - O/L O/L VOLUME encoder operation
detect
28 P72/CLK2 LED2 (TBD) O C - - - - Z - O/L O/L O/L H : ON LED control
29 P71/RXD2 SIRIUS RXD O C - - - - Z - O/L O/L O/L UART SIRIUS control
30 P70/TXD2 SIRIUS TXD O N - - - - Z O/L - O/L O/L UART SIRIUS control
31 P67/TXD1 MO232CI O C - - - - Z - - O/L O/L UART Interface between Main CPU and
external i/o port
32 P66/RXD1 MI232CO I - - - - Ed Z - - O/L O/L UART Interface between Main CPU and
external i/o port
33 P65/CLK1 NC O C - - - Ed Z - - O/L O/L PullDown
34 P64/ NC O C - - - Ed Z - - O/L O/L PullDown
35 P63/TXD0 MOIPI O C - - - - Z - - O/L O/L UART iPod dock control
36 P62/RXD0 MIIPO I - - - - Ed Z - - O/L O/L UART iPod dock control
37 P61/
(CLK0)
NC O C - - - - Z - O/L O/L O/L H : ON
38 P60 NC O C - - - Ed Z - - O/L O/L PullDown
39 P57 SCPUPOWER O C - - - - Z - O/H O/L O/L H : SCPUPOWER ON Sub CPU power control
40 P56 FL_CE1 O C - - - Z - O/L O/L O/L FLD control
41 P55/EPM FRASH EMP/
FL_CLK
O C - - - - Z - O/L O/L O/L Firmware update / FL display
control
42 P54 NC O C - - - Ed Z - - O/L O/L PullDown
43 P53 VOLCLK O C - - - - Z - O/L O/L O/L Volume control
44 P52 VOLDATA O C - - - - Z - O/L O/L O/L Volume control
45 P51 FRONT
HEIGHT RLY
(TBD)
O C - - - - Z - O/L O/L O/L H : Front H Sp ON
46 P50/CE FRASH CE O C - - - - Z - - O/L O/L Firmware upddate control
47 P47 RDSDOUT I - - - - Eu Z - - O/L O/L TUNER control
48 P46 TURDSCLK
(CKTU)
O C - - - - Z - O/L O/L O/L TUNER control
49 P45 TURDSDATA
(DATATU)
O C - - - - Z - O/L O/L O/L TUNER control
50 P44 RDSCE O C - - - - Z - O/L O/L O/L TUNER control
51 P43 RDSRST O C - - - - Z - O/L O/L O/L TUNER control
52 P42 THERMAL
I - - - - Ed Z - - O/L O/L L : PROTECTION Thermal protection detect
53 P41 FRONT A RLY O C - - - - Z - O/L O/L O/L H : Front A Sp ON FRONT A speaker relay control
54 P40 FRONT B RLY O C - - - - Z - O/L O/L O/L H : Front B Sp ON FRONT B speaker relay control
55 P37 STEREO I - Lv - - Ed Z - - O/L O/L STEREO broadcast detect
56 P36 TUSTB O C - - - - Z - O/L O/L O/L TUNER control
57 P35 NC O C - - - Ed Z - O/L O/L O/L
58 P34 TUNED I - Lv - - Eu Z - O/L O/L O/L TUNED det.
59 P33 TUNER MUTE O C - - - - Z - O/L O/H O/L H : MUTE TUNER mute control
60 P32 SIRIUS MUTE O C - - - - Z - O/L O/H O/L H : MUTE SIRIUS mute control
61 P31 MULTI MUTE O C - - - - Z - O/L O/H O/L H : MUTE MULTI ZONE mute control
62VCC VCC -----------
63 P30 SW MUTE O C - - - - Z - O/L O/H O/L H : MUTE SW mute control
64VSS VSS -----------
65 P27 MULTI POWER O C - - - - Z - O/L O/L O/L H : ON MULTI power control
66 P26 SUB UPDATE O C - - - - Z - O/L O/L O/L Sub-CPU F/W update control
67 P25 SIRIUS RESET O C - - - - Z - - O/L O/L SIRIUS control
68 P24 POWER O C - - - Ed Z - O/H O/L O/L H:POWER ON Main relay control
69 P23 PRE POWER O C - - - - Z - O/L O/L O/L H : ON Pre-power components powert
control
70 P22 CENTER RLY O C - - - Ed Z - O/L O/L O/L H : Center Sp ON Center speaker relay control
71 P21 SURROUND
RLY
O C - - - - Z - O/L O/L O/L H : Surround Sp ON Surround speaker relay control
PIN
No.
PIN PIN NAME I/O Type DET
Lv
Cnv
Op
(in)
Op
(ex)
Res
PURE
D
CEC
STBY
STBY
STOP
P. O F F
STOP
Function
To Next Page
