Rear panel
See the page indicated in parentheses ( ).
q w e r t
y
uio
q FM/AM antenna terminals ····················································· (10)
w Analog audio connectors ······················································ (7, 8)
e Speaker terminals ················································· (C 6, 36, 37)
r S-VIDEO/VIDEO connectors ············································· (7, 8, 9)
t Power cord ········································································· (C 5)
y HDMI connectors ··························································· (C 3, 6)
u PRE OUT connectors ············································· (C 6, 36, 37)
i Digital audio connectors ······················································· (7, 8)
o DOCK CONTROL jack ································································ (9)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
