AVR-1910/1620/1610/790/590
(1) Disconnect the connector board.
(2) Remove the screws.
Board to board
Board to board
Board to board
PCB DIGITAL ASSY
PCB MAIN ASSY
PCB VIDEO ASSY
PCB EXT. ASSY (1910/790 model) PCB INPUT ASSY
PCB HDMI ASSY
