46
AVR-1910/1620/1610/790/590
71 P17/INT5 ADVINT1 I -
E
↓
&
L
- - Z - - Z HDMI receiver(ADV7840) control
72 P16/INT4 ADVINT2 I -
E
↓
&
L
- - Z - - Z HDMI receiver(ADV7840) control
73 P15/INT3 ADVINT3 I -
E
↓
&
L
- - Z - - Z HDMI receiver(ADV7840) control
74 P14 OSD SEL O C - - Eu Z - - Z OSD control
75 P13/TXD6 DSP MOSI O C - - Eu Z O/L O/L Z DSP(ADSP-21367-333) control
76 P12/RXD6 DSP MISO I - - - Eu Z - - Z DSP(ADSP-21367-333) control
77 P11/CLK6 DSPICLK O C - - Eu Z O/L O/L Z DSP(ADSP-21367-333) control
78 P10 Z1VSIG.DET I - Lv - Eu Z - - Z Video signal detect
79 P07 PLD WRITE
O C - - - Z O/L O/L Z PLD(EPM240T100C5N) firmware update control
80 P06 PLDCE/TDO O C - - Ed Z O/L O/L Z PLD(EPM240T100C5N) firmware update control
(1910/790 model 9
80 P06 NC O C - - Ed Z O/L O/L Z (1610/1620/590 model)
81 P05 HPD3 O C - - - Z O/L - Z HDMI control (hot plug detect)
82 P04 HPD4 O C - - - Z O/L - Z HDMI control (hot plug detect)
83 P03 DIR INT I - Lv - Eu Z - - Z DIR(LC89058W-VF4A) control
84 P02 NC O C - - - Z Z - Z
85 P01 NC O C - - - Z Z - Z
86 P00 DIR RST1 O C - - - Z O/L O/L O/L DIR(LC89058W-VF4A) control
87 P107/(AN7) DSP RST O C - - - Z O/L O/L Z DSP(ADSP-21367-333) control
88 P106/(AN6) NC O C - - - Z O/L O/L Z
89 P105/(AN5) DSP ROMRST O C - - Ed Z O/L O/L Z Memory for DSP control
90 P104/(AN4) COMPS DET I - Lv - Eu Z - - Z Component video signal detect
91 P103/(AN3) DSP FLAG0 I - Lv - Ed Z - - Z DSP(ADSP-21367-333)control
92 P102/(AN2) DSPICS O C - Eu Z O/L O/L Z DSP(ADSP-21367-333) control
93 P101/(AN1) DSP FLAG1 I - Lv - Ed Z - - Z DSP(ADSP-21367-333) control
94AVSS AVSS -- - ------GND
95 P100/(AN0) NC O C - - - Z O/L O/L Z
96 VREF VREF - - - - - - - - - +3.3V
97 AVCC AVCC - - - - - - - - - +3.3V
98 P97/(SIN4) NC O C - - Eu Z O/L O/L Z
99
P96/(SOUT4)
NC O C - - Eu Z O/L O/L Z
100 P95/(CLK4) VEXP DIN O C - - - Z O/L O/L Z Extended i/o components (BU4094BCFV) control
Pin PIN PIN NAME I/O Type Det
Op
(in)
Op(ex) Res
PURE
D
CEC
STBY
P. O F
F
Function
