Denon AVR-1705 Service Manual

44
AVR-1705/685
C711R 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C713L 00D 963 9006 308 CAP.E. 10UF/50V
C713R 00D 963 9006 308 CAP.E. 10UF/50V
C714L 00D 963 9003 152 C,FILM 0.068UF-J/100V
C714R 00D 963 9003 152 C,FILM 0.068UF-J/100V
C715L 00D 963 9003 152 C,FILM 0.068UF-J/100V
C715R 00D 963 9003 152 C,FILM 0.068UF-J/100V
C716L 00D 963 9006 308 CAP.E. 10UF/50V
C716R 00D 963 9006 308 CAP.E. 10UF/50V
C721 00D 963 9006 447 CAP.E. 47UF/25V
C722 00D 960 9004 602 CAP.E. F0.047UF-Z/50V
C723 00D 963 9006 447 CAP.E. 47UF/25V
C724 00D 960 9004 602 C,CERAMIC F0.047UF-Z/50V
C725,726 00D 963 9005 736 C,FILM 0.0047UF-J/100V
C727-730 00D 963 9004 766 C,FILM 0.1UF-J/100V
C731-736 00D 963 9006 308 CAP.E. 10UF/50V
C741-743 00D 963 9004 575 C,CERAMIC 100PF-J/50V
C751 00D 963 9006 379 CAP.E. 1UF/50V
C756 00D 963 9006 379 CAP.E. 1UF/50V
C761FL 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C761FR 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C761SW 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C762FL 00D 963 9004 575 C,CERAMIC 100PF-J/50V
C762FR 00D 963 9004 575 C,CERAMIC 100PF-J/50V
C762SW 00D 963 9004 575 C,CERAMIC 100PF-J/50V
C763FL 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C763FR 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C763SB 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C763SW 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C764FL 00D 963 9004 627 C,CERAMIC 33PF-J/50V
C764FR 00D 963 9004 627 C,CERAMIC 33PF-J/50V
C764SW 00D 963 9004 643 C,CERAMIC 47PF-J/50V
C765FL 00D 963 9006 308 CAP.E. 10UF/50V
C765FR 00D 963 9006 308 CAP.E. 10UF/50V
C765SW 00D 963 9006 308 CAP.E. 10UF/50V
C771,772 00D 963 9006 447 CAP.E. 47UF/25V
C773 00D 963 9006 379 CAP.E. 1UF/50V
C781C 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C781FL 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C781FR 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C781SB 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C781SL 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C781SR 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C781SW 00D 963 9004 753 C,CERAMIC 0.047UF-Z/50V
C782C 00D 963 9006 476 CAP.E. 4.7UF/50V
C782FL 00D 963 9006 308 CAP.E. 10UF/50V
C782FR 00D 963 9006 308 CAP.E. 10UF/50V
C782SB 00D 963 9006 476 CAP.E. 4.7UF/50V
C782SL 00D 963 9006 308 CAP.E. 10UF/50V
C782SR 00D 963 9006 308 CAP.E. 10UF/50V
C782SW 00D 963 9006 476 CAP.E. 4.7UF/50V
C783C 00D 963 9004 630 C,CERAMIC 39PF-J/50V
C783FL 00D 963 9004 669 C,CERAMIC 56PF-J/50V
C783FR 00D 963 9004 669 C,CERAMIC 56PF-J/50V
C783SB 00D 963 9004 630 C,CERAMIC 39PF-J/50V
C783SL 00D 963 9004 630 C,CERAMIC 39PF-J/50V
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1705 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	6.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX
Digital Signal Processing (DSP)	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	230 W
Optical drive included	No
HDMI in	0
Composite video in	4
S-Video inputs quantity	3
Digital audio optical in	1
S-Video outputs quantity	2

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	10900 g
