Denon AVR-1705 Service Manual

45
AVR-1705/685
C783SR 00D 963 9004 630 C,CERAMIC 39PF-J/50V
C783SW 00D 963 9004 575 C,CERAMIC 100PF-J/50V
C786SW 00D 963 9006 476 CAP.E. 4.7UF/50V
C791,792 00D 963 9006 447 CAP.E. 47UF/25V
OTHER PARTS GROUP
CN701 00D 963 0086 204 CN.WAFER 19P
CN702 00D 963 0085 302 CN.WAFER 17P
CN703 00D 963 0085 409 CN.WAFER 10P
CP551 00D 963 0114 901 CN,WIRE 160MM/14P
00D 963 0094 005 CUSHION (24*18*2.7t)
00D 963 0094 102 PLATE
00D 963 0146 209 TER,RCA 4PIN
00D 960 0268 803 TER,RCA 6PIN
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1705 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	6.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX
Digital Signal Processing (DSP)	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	230 W
Optical drive included	No
HDMI in	0
Composite video in	4
S-Video inputs quantity	3
Digital audio optical in	1
S-Video outputs quantity	2

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	10900 g
