134
Pin Pin Name Symbol I/O Pu/Pd LvCnv STBY STOP
CEC
STBY
Function
62 BCLK/P53(Input only) NC I - - - - - NC
63 P52/RD# NC O - - L L L NC
64 P51/WR1#/BC1# NC O - - L L L NC
65 P50/WR0#/WR# NC O - - L L L NC
66 P77 VIN B O - 3->5 L L L CVBS Select(NJM2595)
67 P76/IRQ14-A TU GPO2_INT I - - L L L TUNER GPIO2 input pin
68 P75 DSP ROMRST O - - I I I Memory reset for DSP (Reset : L)
69
PC7/A23/CS4#-D/CS7#-D/
TxD5
DSP MOSI O DA3VPu - L L L DSP control pin (ADSP21487KSWZ-2B)
70 PC6/A22/CS6#-D/RxD5 DSP MISO I DA3VPu - L L L DSP control pin (ADSP21487KSWZ-2B)
71 PC5/A21/CS5#-D/SCK5 DSPI CLK O DA3VPu - L L L DSP control pin (ADSP21487KSWZ-2B)
72 PC4/A20 DSP RST O - - L L L DSP(ADSP21487KSWZ-2B) reset output pin (Reset : L)
73 PC3/A19 DSP FLAG0 I Pd - L L L DSP control pin (ADSP21487KSWZ-2B)
74 VCC
VCC - - - - - - +3.3V
75 PC2/A18 DSP ICS O DA3VPu - L L L DSP control pin (ADSP21487KSWZ-2B)
76 VSS VSS - - - - - - GND
77 PC1/A17 GRN LED O - - L L L POWER LED control pin(ON:H)
78 PC0/A16 RED LED O - - L/H L H POWER/STANDBY LED control pin (ON:H)
79
PB7/A15/PO31/TIOCA11/
TIOCB11
H/P RL O - - L L L HEADPHONE RELAY Control
80 PB6/A14/PO30/TIOCA11 FRONT RL O - - L L L SPEAKER FRONT RELAY Control
81
PB5/A13/PO29/TIOCA10/
TIOCB10
HIN SELC O - - L L L TC4051 Control(for CEC Standby HDMI detect)
82 PB4/A12/PO28/TIOCA10 TU_SEN O - - L L L TUNER control pin
83
PB3/A11/PO27/TIOCC9/
TIOCD9
C/S RL O - - L L L SPEAKER CEN/SURR RELAY Control
84 PB2/A10/PO26/TIOCC9 NC O - - L L L NC
85
PB1/A9/PO25/TIOCA9/
TIOCB9
D5V POWER O - - L L H Digital 5V power supply control pin(5→3.3V,1.8V)
86 P74/ADTRG3# DIR CE O - - L L L DIR control pin (LC89058W-E)
87 P73
DIR DIN O - - L L L DIR control pin (LC89058W-E)
88 P72 DIR DOUT I DA3VPu - I I I DIR control pin (LC89058W-E)
89
P71/CS4#-C/CS5#-C/
CS6#-C/CS7#-C
DIR CLK O - - L L L DIR control pin (LC89058W-E)
90 P70/CS3#-B/ADTRG2# DIR RST O - - L L L DIR control pin (LC89058W-E)
91 VCC VCC - - - - - - +3.3V
92 PB0/A8/PO24/TIOCA9 7623 ROM HOLD O - - L L L SPI FLASH ROM HOLD control pin (ADV7623)
93 VSS VSS - - - - - - GND
94
PA7/A7/PO23/TIOCA8/
TIOCB8/TCLKH
NC O - - L L L NC
95 PA6/A6/PO22/TIOCA8 VSEL A I - - I I I Master Volume rotation detection pin(Rotary encoder)
96
PA5/A5/PO21/TIOCA7/
TIOCB7/TCLKG
VSEL B I - - I I I Master Volume rotation detection pin(Rotary encoder)
97 PA4/A4/PO20/TIOCA7 NC O - - L L L NC
98
PA3/A3/PO19/TIOCC6/
TIOCD6/TCLKF
DAC(ETHER) MUTE O - - L L L DAC (ETHER) MUTE control pin (PCM5100)MUTE ON="L"
99
PA2/A2/PO18/TIOCC6/
TCLKE
PRE Z2 MUTE(1713E3)/
NC(Except 1713E3)
O/O - - L L L ZONE2 PRE OUT MUTE control pin
100
PA1/A1/PO17/TIOCA6/
TIOCB6
NC O - - L L L NC
101
PA0/A0/BC0#/PO16/
TIOCA6
PRE MUTE O - - L L L PRE SW OUT MUTE control pin
102 PE7/IRQ7-A/D15 ADV7623 INT2 I - - I I I HDMI RECEIVER INT2 output pin (ADV7623)
103 PE6/IRQ6-A/D14 ADV7623 Tx INT I - - I I I HDMI signal detection pin (ADV7623)
104 PE5/IRQ5-A/D13 NC O - - L L L NC
105 PE4/D12 NC O - - L L L NC
106 PE3/D11 NC O - - L L L NC
107 PE2/D10 VOL CLK O - - L L L FUNCTION/VOLUME control pin(NJU72340A)
108 PE1/D9 VOL DATA O - - L L L FUNCTION/VOLUME control pin(NJU72340A)
109 PE0/D8 PLD WRITE O - - L L L A.PLD /JTAG switching control pin
110 PD7/D7 JTAG TDO I - - L L L A.PLD rewriting control pin(JTAG)
111 PD6/D6 JTAG TMS/APLD CS O/O - - L L L A.PLD rewriting & control pin
112 PD5/D5
JTAG TDI/APLD DATA/
DAC DATA
O/O - - L L L A.PLD rewriting & control /DAC control pin
113
PD4/D4
JTAG TCK/APLD CLK/
DAC CLK
O/O - - L L L A.PLD rewriting & control /DAC control pin
114 P64/CS4#-B ADC RST O - - L L L A/D converter control pin(AK5358B)
