Denon AVR-1713 - Page 135

135
Pin Pin Name Symbol I/O Pu/Pd LvCnv STBY STOP
CEC
STBY
Function
115 P63/CS3#-A/CS7#-A THERMAL A I - - L L L PROTECTION Detect(THERMAL A)
116 P62/CS2#-A/CS6#-A E SPI CS O N3VPu - L L L ETHERNET communication control pin(DM860)
117
P61/CS1#/CS2#-B/
CS5#-A/CS6#-B/CS7#-B
DAC MS O - - L L L D/A converter control pin(AK4358VQ)
118
P60/CS0#/CS4#-A/
CS5#-B
DAC RST O - - L L L D/A converter control pin(AK4358VQ)
119 PD3/D3 NC O - - L L L NC
120 PD2/D2 NC O - - L L L NC
121 PD1/D1 FL CLK O - - L L L FL Control Pin
122 PD0/D0 FL DATA O - - L L L FL Control Pin
123 P97/AN15 DA POWER O - - L L L Digital power supply (DA3.3V & DA1.2V) control pin (ON:H)
124 P96/AN14 CEC POWER O - - L L H
CEC power supply (CEC5V & CEC3.3V & CEC1.8V) control
pin for CEC STANDBY.
125 P95/AN13 DV POWER1 O - - L L *
Digital (VIDEO) power supply (DV5V & DV3.3V) control pin.
*CEC STANDBY:MODE1=H, MODE2=L
126 P94/AN12 THERMAL B I - - L L L
PROTECTION Detect(THERMAL B)
127 P93/AN11 MAIN POWER O - - L L L MAIN POWER control pin
128 P92/AN10 CPU POWER O - - L L L
MAIN CPU POWER pin (POWER ON: H CEC ON =
STANDBY: H)
129 P91/AN9 Tx EN O - - L L L Front HDMI(AD8195) Chip Enable
130 VSS VSS - - - - - - GND
131 P90/AN8 MODE I - - I I I MODEL switch input pin (No assign)
132 VCC VCC - - - - - - +3.3V
133 P47/IRQ15-B/AN7 DC DET/ASO I - - I I I PROTECTION Detect(DC DET)/(ASO
134 P46/IRQ14-B/AN6 H/P DET / MIC DET I - - I I I Headphone Detect/MIC Detect
135 P45/IRQ13-B/AN5 KEY3 I SW3VPu - I I I Button input 3
136 P44/IRQ12-B/AN4 KEY2 I SW3VPu - I I I Button input 2
137 P43/IRQ11-B/AN3 KEY1 I SW3VPu - I I I Button input 1
138 P42/IRQ10-B/AN2 E SPI REQ I Pd - I L I ETHERNET communication control pin(DM860)
139 P41/IRQ9-B/AN1 H5V DET I - - I I I HDMI INPUT 5V (for EDID / HOT PLUG) detection pin
140 AVSS
AVSS - - - - - - GND
141 P40/IRQ8-B/AN0 CEC_IN I SW3VPu - I I I CEC-D signal input pin
142 VREF VREF - - - - - - Reference voltage (+3.3V) input pin for A/D port
143 AVCC AVCC - - - - - - +3.3V
144
P05/IRQ13-A/TMO3/
RxD4/TCK
TCK/RXD MITSUBISHI/
NC(NORMRAL)
I/I/I M3VPu - -/-/I -/-/I I NC
