Denon AVR-1713 Service Manual

151
Ref. No. Part No. Part Name Remarks Q'ty New
R1025 00MNN05393610 RES,CHIP(1608/5%/39Kohm)
CRJ10DJ393T
R1026 00MNN05393610 RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T
R1027 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R1030 00MNN05100610 RES,CHIP(1608/5%/10ohm) CRJ10DJ100T
R1038 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R1039 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R1040 00MNN05222610 RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T
R1041 00MNN05122610 RES,CHIP(1608/5%/1.2Kohm) CRJ10DJ122T
R1042 00MNN05122610 RES,CHIP(1608/5%/1.2Kohm) CRJ10DJ122T
R1043 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R1053 00MNN05100610 RES,CHIP(1608/5%/10ohm) CRJ10DJ100T
R1057 00MNN05471610 RES,CHIP(1608/5%/470ohm) CRJ10DJ471T
R1058 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1059 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1060 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R1061 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R1064 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
z
R1066 943124500040S RES,M-OXIDEFILM(1W/4.7ohm)
CRG1SANJ4R7RT
R1067 00MNN05100610 RES,CHIP(1608/5%/10ohm) CRJ10DJ100T
R1071 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R1072 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1073 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1074 00MNN05151610 RES,CHIP(1608/5%/150ohm) CRJ10DJ151T
R1075 00MNN05181610 RES,CHIP(1608/5%/180ohm) CRJ10DJ181T
R1076 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1077 00MNN05151610 RES,CHIP(1608/5%/150ohm) CRJ10DJ151T
R1078 00MNN05151610 RES,CHIP(1608/5%/150ohm) CRJ10DJ151T
R1401 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1402 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R1403 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R1404 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R1405 00MNN05222610 RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T
R1406 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1407 00MNN05821610 RES,CHIP(1608/5%/820ohm) CRJ10DJ821T
R1408 nsp RES,CHIP(1608/5%/18Kohm) CRJ10DJ183T
R1409 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1410 00MNN05473610 RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T
R1411 00MNN05222610 RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T
CAPACITORS GROUP
C1002 nsp CAP,MYLAR(100V/0.1uF/J)
HCQI1H104JZT
C1003 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T
C1004 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
C1005 00MOA22706320 CAP,ELECT(63V/220uF) CCEA1JH221E
C1006 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
C1007 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT
C1009 nsp CAP,CHIP(2012,50V/0.1uF) CCUC1H104KC
C1010 00D9430175108 CAP,ELECT(50V/10uF) CCEA1HH100T
C1011 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C1013 nsp CAP,CHIP(1608,50V/100pF) CCUS1H101JA
C1014 nsp CAP,CHIP(1608,50V/100pF) CCUS1H101JA
C1015 nsp CAP,CHIP(1608,50V/330pF) CCUS1H331JA
C1016 nsp CAP,CHIP(1608,50V/1000pF) CCUS1H102KC
C1017 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT
C1019 00D9430175108 CAP,ELECT(50V/10uF) CCEA1HH100T
C1020 nsp CAP,CHIP(1608,50V/0.01uF) CCUS1H103KC
C1038 943134010670S CAP,ELECT(16V/47uF)-S CCEA1CKS470T
C1039 nsp CAP,CHIP(1608,50V/100pF) CCUS1H101JA
C1050 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C1052 00D9430173003 CAP,ELECT(10V/220uF)-S CCEA1AKS221T
C1053 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C1054 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C1055 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C1065 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
C1066 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C1067 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
