Denon AVR-1713 Service Manual

152
Ref. No. Part No. Part Name Remarks Q'ty New
C1068 nsp CAP,CHIP(1608,50V/0.1uF)
CCUS1H104KC
C1071 nsp CAP,CHIP(1608,50V/220pF) CCUS1H221JA
C1072 nsp CAP,CHIP(1608,50V/220pF) CCUS1H221JA
C1073 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C1076 nsp CAP,CHIP(1608,50V/0.01uF) CCUS1H103KC
C1077 nsp CAP,CHIP(1608,50V/0.01uF) CCUS1H103KC
C1081 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C1401 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C1402 nsp CAP,ELECT(50V/1uF)-S CCEA1HKS1R0T
C1403 nsp CAP,CHIP(1608,50V/100pF) CCUS1H101JA
C1405 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T
C1406 nsp CAP,CHIP(1608,50V/0.047uF) CCUS1H473KC
C1407 nsp CAP,ELECT(16V/100uF)-S CCEA1CKS101T
C1408 nsp CAP,CHIP(1608,50V/82pF) CCUS1H820JA
C1410 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
C1411 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
C1414 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C1415 nsp CAP,CHIP(1608,50V/1000pF) CCUS1H102KC
C1417 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C1424 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
OTHERS PARTS GROUP
BD141 nsp FERRITECHIPBEAD(1608/60R)
CLZ9R005Z
BK101 nsp BRACKET,FIP CMD1A572
BK102 nsp BRACKET,FIP CMD1A572
BK103 nsp BRACKET,PCB CMD1A629
BN103 nsp WIRE,ASS'Y CWB1B005050HC *
BN104 nsp WIRE,ASS'Y
CWB1C205350LC001 *
BN12A nsp WIRE,ASS'Y
CWB1B005080CC *
BN13A nsp WIRE,ASS'Y
CWB1B003080CC
CN101 nsp WAFER,FFC1.25mm,ANGLE CJP25GB286ZN *
CN102 nsp WAFER/ANGLE/2.5mm/07P
CJP07GB03ZY
CN103 nsp LOCK-WAFER/ANGLE/2MMPITCH/5PIN CJP05GJ288ZY
CN104 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/3PIN CJP03GI288ZY *
z
F1001 943652000620S FUSE(372Series/100mA/TR5)
CBA2D0100A3EYT
FL101 943172100150S V.F.D(FUTABA,18-BT-02GINK) CFL18BT021GINK
JK101 943643101590S JACK,USBSTRAIGHT(BLACK1.5A) CJJ9X010Z *
JK104 90M-YT004500R JACK,PHONES(6.35mm,SILVER)
CJJ2E026Z
JK603 943643100160S JACK,MONO,3.5mm CJJ1D001Z
L1001 nsp FERRITECHIPBEAD(1608/60R) CLZ9R005Z
L1003 nsp FERRITE,CHIPBEAD(4516/60R) CLZ9Z014Z
L1004 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
L1005 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
L6007 nsp FERRITECHIPBEAD(1608/60R) CLZ9R005Z
L6008 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
LUG11 nsp WIRE,ASS'Y CWE8102100RV
LUG13 nsp WIRE,ASS'Y CWE8102180RV
RC101 943262100140S SENSOR,REMOCON(37.9KHz) CRVHM238RT12
SW101 90M-SP001400R SW,TACT CST1A023ZT
SW102 90M-SP001400R SW,TACT CST1A023ZT
SW103 90M-SP001400R SW,TACT CST1A023ZT
SW104 90M-SP001400R SW,TACT CST1A023ZT
SW105 90M-SP001400R SW,TACT CST1A023ZT
SW106 90M-SP001400R SW,TACT CST1A023ZT
SW107 90M-SP001400R SW,TACT CST1A023ZT
SW108 90M-SP001400R SW,TACT CST1A023ZT

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
