Denon AVR-1713 Service Manual

155
Ref. No. Part No. Part Name Remarks Q'ty New
R6033 nsp RES,CHIP(2012/5%/1Mohm) CRJ18AJ105T
CAPACITORS GROUP
C3001 00D9430062101
CAP,ELECT(16V/100uF) CCEA1CH101T
C3005 00MOF15104040 CAP,METAL-FILM(100V/0.1uF) CCME2A104JXT
C3006 943134010620S CAP,ELECT(25V/4700uF) CCEA1EH472E
C3007 943134001290S CAP,ELECT(25V/2200uF) CCEA1EH222E
C3008 00D9430062101 CAP,ELECT(16V/100uF) CCEA1CH101T
C3012 00D9430103905 CAP,ELECT(16V/470uF) CCEA1CH471T
C3013 00D9430062101 CAP,ELECT(16V/100uF) CCEA1CH101T
C3020 00D9430062101 CAP,ELECT(16V/100uF) CCEA1CH101T
C3021 00D9430062101 CAP,ELECT(16V/100uF) CCEA1CH101T
C3024 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
z
C6001 963132011940S
CAP,CERAMIC(X1/Y2,0.01uF,AC250V) CCKDKY103MFM
z
C6002 963132011940S
CAP,CERAMIC(X1/Y2,0.01uF,AC250V) CCKDKY103MFM
z
C6003 963132011940S
CAP,CERAMIC(X1/Y2,0.01uF,AC250V) CCKDKY103MFM
C6004 943134501590S CAP,ELECT(200V/100uF),105'C
1613E3,
1713E3
CCET200NHA101ES
C6004 963134010200S CAP,ELECT(400V/100UF,18X40,NHA)
1713E2,
1713E1C,
1723E1C
CCET400NHA101ES
C6005 nsp CAP,CHIP(1608,50V/0.047uF) CCUS1H473KC
C6006 nsp CAP,CHIP(1608,50V/0.01uF) CCUS1H103KC
C6007 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C6008 00D9430175108 CAP,ELECT(50V/10uF),105'C CCEA1HNXA100TS
C6011 963132010120S CAP,CERAMIC(DC1KV/1000pF) CCKDDEH102KCM
C6012 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C6013 00MOA47602520 CAP,ELECT(25V/47uF),105'C CCEA1ENXA470TS
C6014 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C6015 nsp CAP,CHIP(1608,6.3V/4.7uF,MURATAGRM18) CCUS0J475KC
C6016 963134010220S CAP,ELECT(6.3V/5600uF) CCEA0JNXA562ES
C6017 963134010220S CAP,ELECT(6.3V/5600uF) CCEA0JNXA562ES
C6018 963134010220S CAP,ELECT(6.3V/5600uF) CCEA0JNXA562ES
C6020 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C6021 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C6022 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
z
C6023 963132011930S
CAP,CERAMIC(X1/Y1,2200P,AC250V) CCKDKX222MEM
C6024 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
OTHERS PARTS GROUP
BK301 nsp
BRACKET,PCB CMD1A569
BK302 nsp BRACKET,PCB CMD1A569
BK601 nsp BRACKET,PCB(A) CMD2A188
BK602 nsp BRACKET,PCB(A) CMD2A188
BK603 nsp BRACKET,PCB CMD1A629
BN301 nsp WIRE,ASS'Y CWB1C0091203D *
BN601 nsp
WIRE,ASS'Y CWB1D0051503D *
CN302 nsp
WAFER/STRAIGHT/2.5mm/5P CJP05GA01ZY
CN601 nsp WAFER,2P,3.96mm CJP02KA060ZY
CN602 nsp WAFER,2P,7.92mm CJP02GA89ZY
z
CX601 943139500020S
CAP,POLYPROPYLENEFILM HCQF2E104KZE
z
CY601 963134011730S
CAP,CERAMIC(X1/Y1,470P,AC250V) CCKDKX471KBM
z
CY602 963134011730S
CAP,CERAMIC(X1/Y1,470P,AC250V) CCKDKX471KBM
z
F3001 00D2061096006
FUSE(218Series,250V/1.25A) KBA2C1250TLEY
z
F3002 00D2061096006
FUSE(218Series,250V/1.25A) KBA2C1250TLEY
z
F6001 963652010510S
FUSE(S506Series,250V,2A)
1613E3,
1713E3
CBA2C2000TLEC
z
F6001 963652010500S
FUSE(S506Series,250V,1.6A)
1713E2,
1713E1C,
1723E1C
CBA2C1600TLEC

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
