Denon AVR-1713 Service Manual

156
Ref. No. Part No. Part Name Remarks Q'ty New
z
F6002 90M-FS001430R
FUSE(218Series,250V/6.3A)
1613E3,
1713E3
KBA2C6300TLEY
z
F6002 90M-FS001420R
FUSE(218Series,250V/3.15A)
1713E2,
1713E1C,
1723E1C
KBA2C3150TLEY
z
LF602 963111010230S
LINEFILTER,27uH
1613E3,
1713E3
CLZ9Z126Z
z
LF602 943111100410S
LINEFILTER,50uH
1713E2,
1713E1C,
1723E1C
CLZ9Z133Z *
z
RY601 963682010370S
RELAY,HL31-1AT-5H,DC5V,1C1P CSL1C006ZE
z
T6001 963102010240S
TRANS,SWITCHING(ST-4430A) CLT9Z067ZE
TW91 nsp 2PWIREASS'Y(100MM) 1713E2 CWZPM5003TW91
ZD608 00D2760762958 DIODE,ZENER,1/2W,39V
1613E3,
1713E3
CVDZJ39BT
ZD609 00D2760762958 DIODE,ZENER,1/2W,39V
1613E3,
1713E3
CVDZJ39BT
ZD610 00D2760762958 DIODE,ZENER,1/2W,39V
1613E3,
1713E3
CVDZJ39BT
ZD611 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT
ZD612 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT
ZD613 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT
ZD614 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT
ZD615 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT
ZD616 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT
ZD617 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT
ZD618 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT
ZD619 00D9600095607 DIODE,ZENER,1/2W,5.6V CVDZJ5.6BT
ZD620 00D2760762958 DIODE,ZENER,1/2W,39V CVDZJ39BT
ZD621 00D9430196306 DIODE,ZENER,1/2W,7.5V
1613E3,
1713E3
CVDZJ7.5BT
ZD621 943202000940S DIODE,ZENER,1/2W,16V
1713E2,
1713E1C,
1723E1C
CVDZJ16BT
nsp HOLDER,FUSE F3001 KJCFC5S
nsp HOLDER,FUSE F3002 KJCFC5S
nsp HOLDER,FUSE F6001 KJCFC5S
nsp HOLDER,FUSE F6002 KJCFC5S

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
