Denon AVR-1713 Service Manual

159
Ref. No. Part No. Part Name Remarks Q'ty New
R5213 00MGD05272160
RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T
R5214 00MGD05561160 RES,CARBON(1/5W,560ohm,J) CRD20TJ561T
R5215 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5216 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5217 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5218 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5219 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5220 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5221 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5222 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5223 RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T
R5224 00MGD05274160 RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T
R5225 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
z
R5226 943252100130S
PTCTHEMISTORS,CHIP(95C) CRTB59641A0095 *
R5227 00MGD05562160
RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T
R5229 00MGD05153160 RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T
R5230 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5231 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5232 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5301 00MGD05104160 RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T
R5302 00MGD05681160 RES,CARBON(1/5W,680ohm,J) CRD20TJ681T
R5303 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R5304 00MGD05183160 RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T
R5305 00MGD05122160 RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T
R5306 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT
R5307 00MGD05221160 RES,CARBON(1/5W,220ohm,J) CRD20TJ221T
R5308 00MGD05474160 RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T
R5309 00MGD05333160 RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T
R5310 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R5311 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5312 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5313 00MGD05272160 RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T
R5314 00MGD05561160 RES,CARBON(1/5W,560ohm,J) CRD20TJ561T
R5315 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5316 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5317 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5318 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5319 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5320 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5321 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5322 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5323 RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T
R5324 00MGD05274160 RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T
R5325 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
z
R5326 943252100130S
PTCTHEMISTORS,CHIP(95C) CRTB59641A0095 *
R5327 00MGD05562160
RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T
R5329 00MGD05153160 RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T
R5330 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5331 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5332 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5401 00MGD05104160 RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T
R5402 00MGD05681160 RES,CARBON(1/5W,680ohm,J) CRD20TJ681T
R5403 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R5404 00MGD05183160 RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T
R5405 00MGD05122160 RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T
R5406 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT
R5407 00MGD05221160 RES,CARBON(1/5W,220ohm,J) CRD20TJ221T
R5408 00MGD05474160 RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T
R5409 00MGD05333160 RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T
R5410 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R5411 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5412 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5413 00MGD05272160 RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T
R5414 00MGD05561160 RES,CARBON(1/5W,560ohm,J) CRD20TJ561T
R5415 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5416 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5417 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
