Denon AVR-1713 Service Manual

160
Ref. No. Part No. Part Name Remarks Q'ty New
R5418 943124500040S
RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5419 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5420 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5421 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5422 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5423 RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T
R5424 00MGD05274160 RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T
R5425 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
z
R5426 943252100130S
PTCTHEMISTORS,CHIP(95C) CRTB59641A0095 *
R5427 00MGD05562160
RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T
R5429 00MGD05153160 RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T
R5430 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5431 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5432 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5501 00MGD05104160 RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T
R5502 00MGD05681160 RES,CARBON(1/5W,680ohm,J) CRD20TJ681T
R5503 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R5504 00MGD05183160 RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T
R5505 00MGD05122160 RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T
R5506 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT
R5507 00MGD05221160 RES,CARBON(1/5W,220ohm,J) CRD20TJ221T
R5508 00MGD05474160 RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T
R5509 00MGD05333160 RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T
R5510 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R5511 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5512 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5513 00MGD05272160 RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T
R5514 00MGD05561160 RES,CARBON(1/5W,560ohm,J) CRD20TJ561T
R5515 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5516 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5517 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5518 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5519 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5520 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5521 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5522 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5523 RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T
R5524 00MGD05274160 RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T
R5525 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
z
R5526 943252100130S
PTCTHEMISTORS,CHIP(95C) CRTB59641A0095 *
R5527 00MGD05562160
RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T
R5529 00MGD05153160 RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T
R5530 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5531 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5532 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5701 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R5702 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5703 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5704 nsp RES,M-OXIDEFILM(1W/100ohm) CRG1SANJ101RT
R5705 00MGD05104160 RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T
R5706 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R5707 00MGD05104160 RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T
R5708 00MGD05153160 RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T
R5711 00MGD05122160 RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T
R5712 00MGD05222160 RES,CARBON(1/5W,2.2Kohm,J) CRD20TJ222T
R5713 00MGD05222160 RES,CARBON(1/5W,2.2Kohm,J) CRD20TJ222T
R5715 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT
R5716 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT
R5717 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT
R5721 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5722 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5723 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5724 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5725 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5726 nsp RES,M-OXIDEFILM(2W/470ohm) CRG2SANJ471RT
R5727 nsp RES,M-OXIDEFILM(2W/470ohm) CRG2SANJ471RT

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
