Denon AVR-1802 Service Manual

31
AVR-1802/882
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
R206 963 9004 232 Carbon chip 220 kohm 1/16W
R208 963 9003 398 Carbon chip 1 kohm 1/16W
R209 963 9004 070 Carbon chip 10 kohm 1/16W
R210FL,FR 963 9004 313 Carbon chip 4.3 kohm 1/16W
R211 963 9004 070 Carbon chip 10 kohm 1/16W
R212 963 9003 398 Carbon chip 1 kohm 1/16W
R213FR 963 9004 151 Carbon chip 15 kohm 1/16W
R214FL,FR 963 9004 151 Carbon chip 15 kohm 1/16W
R215FL,FR 963 9003 385 Carbon chip 100 ohm 1/16W
R216 963 9004 070 Carbon chip 10 kohm 1/16W E3,E2
R216FL,FR 963 9004 083 Carbon chip 100 kohm 1/16W
R217 963 9004 151 Carbon chip 15 kohm 1/16W
R217FL,FR 963 9004 410 Carbon chip 6.2 kohm 1/16W
R218 963 9004 070 Carbon chip 10 kohm 1/16W E2,E1,E1C,E1H,E1T
R219,220 963 9004 070 Carbon chip 10 kohm 1/16W
R223,224 963 9004 070 Carbon chip 10 kohm 1/16W E2
R220SW 963 9004 481 Carbon chip 8.2 kohm 1/16W
R221SW 963 9004 287 Carbon chip 3.6 kohm 1/10W
R222SW 963 9004 481 Carbon chip 8.2 kohm 1/16W
R223,224 963 9003 372 Carbon chip 0 ohm 1/16W
R223SW 963 9003 385 Carbon chip 100 ohm 1/16W
R224SW 963 9004 083 Carbon chip 100 kohm 1/16W
R225 963 9004 245 Carbon chip 2.2Mohm 1/16W E2
R229,230 960 9003 807 Metal film 100 ohm 1/4W
R237 963 9003 398 Carbon chip 1 kohm 1/16W
R239C 963 9004 083 Carbon chip 100 kohm 1/16W
R239FL,FR 963 9004 083 Carbon chip 100 kohm 1/16W
R239SL,SR 963 9004 083 Carbon chip 100 kohm 1/16W
R239SW 963 9004 083 Carbon chip 100 kohm 1/16W
R240C 963 9003 385 Carbon chip 100 ohm 1/16W
R240FL,FR 963 9003 385 Carbon chip 100 ohm 1/16W
R240SL,SR 963 9003 385 Carbon chip 100 ohm 1/16W
R240SW 963 9003 385 Carbon chip 100 ohm 1/16W
R241C 963 9004 083 Carbon chip 100 kohm 1/16W
R241FL,FR 963 9004 083 Carbon chip 100 kohm 1/16W
R241SL,SR 963 9004 083 Carbon chip 100 kohm 1/16W
R241SW 963 9004 083 Carbon chip 100 kohm 1/16W
R242C 963 9004 478 Carbon chip 7.5 kohm 1/10W
R242FL,FR 963 9004 478 Carbon chip 7.5 kohm 1/10W
R242SL,SR 963 9004 478 Carbon chip 7.5 kohm 1/10W
R242SW 963 9004 449 Carbon chip 6.8 kohm 1/16W
R243C 963 9004 070 Carbon chip 10 kohm 1/16W
R243FL,FR 963 9004 070 Carbon chip 10 kohm 1/16W
R244C 963 9004 135 Carbon chip 1.3 kohm 1/10W
R244FL,FR 963 9004 135 Carbon chip 1.3 kohm 1/10W
R244SL,SR 963 9004 135 Carbon chip 1.3 kohm 1/10W
R244SW 963 9004 407 Carbon chip 620 ohm 1/16W
R246C 963 9004 083 Carbon chip 100 kohm 1/16W
R246SL,SR 963 9004 083 Carbon chip 100 kohm 1/16W
R246SW 963 9004 083 Carbon chip 100 kohm 1/16W
R247C 963 9004 339 Carbon chip 470 ohm 1/16W
R247SL,SR 963 9004 339 Carbon chip 470 ohm 1/16W
R247SW 963 9004 339 Carbon chip 470 ohm 1/16W
R250 963 9004 368 Carbon chip 470 kohm 1/16W
R255 963 9004 368 Carbon chip 470 kohm 1/16W
R261 963 9004 122 Carbon chip 12 kohm 1/16W
R262 963 9004 070 Carbon chip 10 kohm 1/16W
R263,264 963 9004 122 Carbon chip 12 kohm 1/16W
R265~271 963 9004 339 Carbon chip 470 ohm 1/16W
R336 963 9004 465 Carbon chip 75 ohm 1/16W
R337 963 9004 342 Carbon chip 4.7 kohm 1/16W
R338 963 9004 339 Carbon chip 470 ohm 1/16W
R339 963 9004 119 Carbon chip 1.2 kohm 1/16W
R340~348 963 9004 436 Carbon chip 680 ohm 1/16W
R349 963 9004 339 Carbon chip 470 ohm 1/16W
R349FL~402FL 963 9004 397 Carbon chip 56 kohm 1/16W
R350,351 963 9004 245 Carbon chip 2.2 Mohm 1/16W
R407 963 9004 342 Carbon chip 4.7 kohm 1/16W
CAPACITORS GROUP
BC201 963 0061 504 Electrolytic 8200 µ F/5.5V
C202,203 963 9004 698 Ceramic chip 0.01 µ F/50V
C204 Electrolytic 4.7 µ F/50V
C206 Electrolytic 47 µ F/16V E2
C207 963 9004 546 Ceramic 0.01 µ F/16V E2
C208 963 9004 805 Ceramic 270pF/50V E2
C209 Electrolytic 10 µ F/35V E2
C210 963 9004 698 Ceramic chip 0.01 µ F/50V E2
C211 963 9004 614 Ceramic chip 27pF/50V E2
C211SW 963 9004 575 Ceramic chip 100pF/50V
C212 963 9004 614 Ceramic chip 27pF/50V E2
C212SW 963 9004 643 Ceramic chip 47pF/50V
C213-219 963 9004 753 Ceramic chip 0.047 µ F/50V
C213FL,FR 963 9004 575 Ceramic chip 100pF/50V
C218FL,FR 963 9004 627 Ceramic chip 33pF/50V
C219FL,FR Electrolytic 10 µ F/35V
C219SW,220 Electrolytic 10 µ F/35V
C221FL,FR Electrolytic 4.7 µ F/50V
C222SW Electrolytic 4.7 µ F/50V
C223SL,SR Electrolytic 4.7 µ F/50V
C225,226 963 9004 753 Ceramic chip 0.047 µ F/50V
C227 Electrolytic 10 µ F/35V
C228-C234 963 9004 575 Ceramic chip 100pF/50V
C230C,231C Electrolytic 4.7 µ F/50V
C231FL,FR Electrolytic 10 µ F/35V
C231SL,SR Electrolytic 4.7 µ F/50V
C231SW Electrolytic 4.7 µ F/50V
C232C 963 9004 669 Ceramic chip 56pF/50V
C232FL,FR 963 9004 669 Ceramic chip 56pF/50V
C232SL,SR 963 9004 630 Ceramic chip 39pF/50V
C232SW 963 9004 669 Ceramic chip 56pF/50V

Denon AVR-1802 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	115 W
Power output per channel (20-20KHz@8 Ohm)	80 W
AC input voltage	120 V
AC input frequency	60 Hz
Equalizer	Yes
Audio decoders	DTS, Dolby Digital, Dolby Pro Logic II
3D	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	0
Composite video in	5
S-Video inputs quantity	4
Digital audio coaxial in	1
Digital audio optical in	3

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	171 mm
Weight	10900 g
