Denon AVR-1802 Service Manual

32
AVR-1802/882
Ref. No. Part No. Part Name Remarks
C233C 963 9004 724 Ceramic chip 2200pF/50V
C233FL,FR 963 9004 724 Ceramic chip 2200pF/50V
C234FL,FR 963 9004 672 Ceramic chip 680pF/50V
C235SW 963 9004 575 Ceramic chip 100pF/50V
C236 Electrolytic 4.7
µ F/50V
C237 Electrolytic 0.1
µ F/50V
C239 963 9004 753 Ceramic chip 0.047
µ F/50V
C240 Electrolytic 1 µ F/50V
C241 Electrolytic 10 µ F/35V
C242 963 9004 588 Ceramic chip 100pF/50V
C243,244 963 9004 753 Ceramic chip 0.047
µ F/50V
C243C 963 9004 672 Ceramic chip 680pF/50V
C245 963 9004 575 Ceramic chip 100pF/50V
C246 Electrolytic 10
µ F/35V
C246SW Electrolytic 4.7 µ F/50V
C247 963 9004 575 Ceramic chip 100pF/50V
C248 963 9004 588 Ceramic chip 1000pF/50V
C249 960 9003 108 Ceramic 0.022 µ F/25V
C250 963 9004 575 Ceramic chip 100pF/50V
C301-304 963 9004 698 Ceramic chip 0.01 µ F/50V
C305-307 963 9004 575 Ceramic chip 100pF/50V
C309 963 9004 737 Ceramic chip 0.022 µ F/25V
C311 963 9004 494 Ceramic 30pF/50V
C312 963 9004 753 Ceramic chip 0.047 µ F/50V
C313 963 9004 504 Ceramic 0.01 µ F/50V
C314 963 0021 900 Mylar film 0.047 µ F/100V
C315 Electrolytic 1 µ F/50V
C316 Electrolytic 10 µ F/50V
C317 Electrolytic 47 µ F/10V
C318 963 0021 900 Mylar film 0.047 µ F/100V
C319 Electrolytic 10 µ F/35V
C320 Electrolytic 1 µ F/50V
C321 963 0021 900 Mylar film 0.047 µ F/100V
C322 Electrolytic 47 µ F/10V
C323 963 9004 766 Mylar film 0.1 µ F/100V
C324 Electrolytic 1 µ F/50V
C325 963 9004 575 Ceramic chip 100pF/50V
C326 Electrolytic 4.7 µ F/50V
C327 Electrolytic 1 µ F/50V
C328 963 9004 753 Ceramic chip 0.047 µ F/50V
C3010 Electrolytic 47 µ F/10V
C3020 963 9004 818 Ceramic 0.1 µ F/50V
C3030 963 9004 591 Ceramic chip 22pF/50V
Ref. No. Part No. Part Name Remarks Q'ty
OTHER PARTS GROUP
CB201,202 963 0053 800 BEADS INDUCTOR 2
CN301 960 0197 602 17P FFC connector base 1
CN302 963 0087 300 3P connector cord 1
CP301 960 0197 709 17P FFC connector base 1
CP301 963 0049 102 3P connector base 1
CP401 963 0087 407 16P connector base (TUC-P) 1
CP551 963 0087 504 19P connector base (TUC-P) 1
CP552 963 0087 601 18P connector base (TUC-P) 1
CP601,602 963 0086 903 5P connector base (TUC-P) 2
CP603 963 0087 009 6P connector base (TUC-P) 1
CP605 963 0086 806 9P connector base (TUC-P) 1
CP701 963 0087 708 12P connector base (TUC-P) 1
CP702 963 0087 805 11P connector base (TUC-P) 1
CP801,802 963 0087 902 17P connector base (TUC-P) 2
CP803 963 0088 008 10P connector base (TUC-P) 1
CP901 963 0060 806 11P connector base 1
GP301 963 0088 202 1P contact Ass’y1
GP303 963 0088 202 1P contact Ass’y1
J324,325 963 9003 369 Carbon chip 0 ohm 1/8W 2
J326 963 9003 372 Carbon chip 0 ohm 1/16W 1
J340 963 9003 369 Carbon chip 0 ohm 1/8W 1
J342,343 963 9003 369 Carbon chip 0 ohm 1/8W 2
JK301 963 0067 508 3P pin jack 1
JP301 963 9003 369 Carbon chip 0 ohm 1/8W 1
L301 960 0010 307 Inductor 10 µ H1
L302 960 0128 008 Inductor 100 µ H1
L3010 963 0050 803 Inductor 4.7 µ H1
SW301~322 963 0045 708 Tact switch 22
VEC301,302 960 0181 207 Rotary encoder 2
X201 960 0181 003 Resonator CST12.0MTW-TF01 1
X202 960 0091 805 Crystal 4.332MHz E2 1
 960 0184 408 FLT holder 1
 960 0180 509 FLT (16-ST-42GNK) 1

Denon AVR-1802 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	115 W
Power output per channel (20-20KHz@8 Ohm)	80 W
AC input voltage	120 V
AC input frequency	60 Hz
Equalizer	Yes
Audio decoders	DTS, Dolby Digital, Dolby Pro Logic II
3D	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	0
Composite video in	5
S-Video inputs quantity	4
Digital audio coaxial in	1
Digital audio optical in	3

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	171 mm
Weight	10900 g
