Denon AVR-1802 Service Manual

33
AVR-1802/882
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
CNT P.W.B. ASS'Y
R405 960 9003 807 Metal film 100 ohm 1/4W
R406 963 9004 342 Carbon chip 4.7 kohm 1/16W
R407 963 9004 407 Carbon chip 620 ohm 1/16W E3,E1,E1C,E1H,E1T
R407 963 9004 436 Carbon chip 680 ohm 1/16W E2
R408 963 9004 119 Carbon chip 1.2 kohm 1/16W E3,E1,E1C,E1H,E1T
R408 963 9004 436 Carbon chip 680 ohm 1/16W E2
R409 963 9004 339 Carbon chip 470 ohm 1/16W
R411 963 9004 452 Carbon chip 68 kohm 1/16W
R412 963 9004 834 Carbon chip 5.6 kohm 1/16W
R413 960 9006 503 Metal film 220ohm 1/4W
R414 963 9004 216 Carbon chip 2.2 kohm 1/16W
R415 963 9003 398 Carbon chip 1 kohm 1/16W
R416 241 2379 945 Metal film 680 ohm 1/4W
R417 963 9003 398 Carbon chip 1 kohm 1/16W
R418 963 9004 274 Carbon chip 33 kohm 1/16W
R420 963 9003 372 Carbon chip 0 ohm 1/16W
R426,427 963 9004 070 Carbon chip 10 kohm 1/16W
R428 963 9004 847 Carbon chip 3.3 kohm 1/16W E3
R428 963 9004 070 Carbon chip 10 kohm 1/16W E2
R428 963 9004 449 Carbon chip6.8 kohm 1/16W E1,E1C,E1H,E1T
R429 963 9004 850 Carbon chip 82 ohm 1/16W
R430 960 9003 807 Metal film 100 ohm 1/4W
R431 963 9004 371 Carbon chip 5.1 kohm 1/16W
R432 963 9004 070 Carbon chip 10 kohm 1/16W
R434 960 9003 807 Metal film 100 ohm 1/4W
R435 963 9004 847 Carbon chip 3.3 kohm 1/16W
R437 963 9004 083 Carbon chip 100 kohm 1/16W
R438,439 963 9004 083 Carbon chip 100 kohm 1/16W E3,E2,E1,E1C,E1H,E1T
R438,439 963 9004 164 Carbon chip 150 kohm 1/16W E2
R440,441 963 9004 863 Carbon chip 120 kohm 1/16W E3,E2,E1,E1C,E1H,E1T
R440,441 963 9004 232 Carbon chip 220 kohm 1/16W E2
R442,443 963 9004 847 Carbon chip 3.3 kohm 1/16W E3,E2,E1,E1C,E1H,E1T
R442,443 963 9004 216 Carbon chip 2.2 kohm 1/16W E2
R444,445 963 9004 481 Carbon chip 8.2 kohm 1/16W E3,E2,E1,E1C,E1H,E1T
R444,445 963 9004 847 Carbon chip 3.3 kohm 1/16W E2
R448 963 9004 216 Carbon chip 2.2 kohm 1/16W
R449 963 9004 216 Carbon chip 2.2 kohm 1/16W E2
R450 963 9003 398 Carbon chip 1 kohm 1/16W E2
R455 963 9004 876 Carbon chip 330 ohm 1/16W
R456 963 9003 385 Carbon chip 100 ohm 1/16W
R458,459 963 9004 342 Carbon chip 4.7 kohm 1/16W
R460,461 963 9004 245 Carbon chip 2.2 Mohm 1/16W
R462~465 963 9004 339 Carbon chip 470 ohm 1/16W
R467,468 963 9004 245 Carbon chip 2.2 Mohm 1/16W
R470 963 9003 398 Carbon chip 1 kohm 1/16W
R471VT 963 9004 203 Carbon chip 220 ohm 1/16W
R474 963 9004 889 Carbon chip 180 ohm 1/16W E3,E2
R475 963 9004 122 Carbon chip 12 kohm 1/16W
R476 963 9004 397 Carbon chip 56 kohm 1/16W
R478 963 9004 070 Carbon chip 10 kohm 1/16W
R479 963 9004 083 Carbon chip 100 kohm 1/16W
SEMICONDUCTORS GROUP
IC401 963 0043 700 IC LC72131
IC402 963 0043 904 IC LA1266
IC403 963 0044 000 IC LA3401
IC551 960 0174 502 IC NJM2068DD
IC552 963 0043 506 IC TC9184AP
IC601 963 0083 304 IC BA7626
IC602 963 0074 504 IC BU2090F
IC651,652 963 0083 304 IC BA7626
IC663 963 0057 806 IC KIA78R05PI
Q401 960 0189 102 Transistor KTC3880S-O
Q402~404 269 0083 901 Transistor DTA114EK
Q405,406 960 0196 603 Transistor KTC2874B
Q407 963 0024 208 Transistor DTC114YK
Q408 269 0083 901 Transistor DTA114EK
Q409 960 0189 102 Transistor KTC3880S-O E2
Q551 960 0196 700 Transistor KTC3200BL
Q551SW ,552SW 960 0196 603 Transistor KTC2874B
Q552 960 0196 302 Transistor KTA1268BL
Q553~555 269 0046 906 Transistor DTA114ES
Q553T 960 0196 904 Transistor DTC114YS (NPN)
Q601~603 960 0005 105 Transistor KTA1266Y
Q604~606 963 0075 406 Transistor DTC114TS
Q651~656 960 0005 105 Transistor KTA1266Y
D403 960 0197 000 Diode KDS160
D404~406 963 0020 309 Diode 1SS133T
D551,551T 963 0020 309 Diode 1SS133T
D552-561 963 0020 309 Diode 1SS133T
D562,563 963 0058 407 Diode IN4007
D564 960 0095 500 Zener diode MTZJ5.1B
D565 963 0020 309 Diode 1SS133T
D601~606 960 0197 000 Diode KDS160
D651~D656 960 0197 000 Diode KDS160
D652T 963 0061 601 Electrolytic 3300 µ F/10V
D657,658 963 0058 407 Diode IN4007
D901,902 960 0197 000 Diode KDS160
ZD401 960 0095 500 Zener diode MTZJ5.1B
RESISTORS GROUP
R401 963 9004 821 Carbon chip 10 ohm 1/16W
R403 963 9004 339 Carbon chip 470 ohm 1/16W
R404 963 9004 083 Carbon chip 100 kohm 1/16W

Denon AVR-1802 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	115 W
Power output per channel (20-20KHz@8 Ohm)	80 W
AC input voltage	120 V
AC input frequency	60 Hz
Equalizer	Yes
Audio decoders	DTS, Dolby Digital, Dolby Pro Logic II
3D	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	0
Composite video in	5
S-Video inputs quantity	4
Digital audio coaxial in	1
Digital audio optical in	3

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	171 mm
Weight	10900 g
