Denon AVR-1802 Service Manual

39
AVR-1802/882
Ref. No. Part No. Part Name Remarks
C873C 963 9004 672 Ceramic chip 680pF/50V
C873FL,FR 963 9004 672 Ceramic chip 680pF/50V
C873SL,SR 963 9004 672 Ceramic chip 680pF/50V
C873SW 963 9004 672 Ceramic chip 680pF/50V
C874C 963 9004 672 Ceramic chip 680pF/50V
C874FL,FR 963 9004 672 Ceramic chip 680pF/50V
C874SL,SR 963 9004 672 Ceramic chip 680pF/50V
C874SW 963 9004 672 Ceramic chip 680pF/50V
C875C Electrolytic 10
µ F/35V
C875FL,FR Electrolytic 10
µ F/35V
C875SL,SR Electrolytic 10 µ F/35V
C875SW Electrolytic 10 µ F/35V
C876C 963 9004 740 Ceramic chip 3300pF/50V
C876FL,FR 963 9004 740 Ceramic chip 3300pF/50V
C876SL,SR 963 9004 740 Ceramic chip 3300pF/50V
C876SW 963 9004 740 Ceramic chip 3300pF/50V
C880C Electrolytic 10 µ F/35V
C880FL,FR Electrolytic 10 µ F/35V
C880SL,SR Electrolytic 10 µ F/35V
C880SW Electrolytic 10 µ F/35V
C908,909 963 9004 614 Ceramic chip 27pF/50V
C916 963 9004 711 Ceramic chip 0.1 µ F/50V
C917 Electrolytic 10 µ F/35V
C918 963 9004 711 Ceramic chip 0.1 µ F/50V
C919 963 9004 698 Ceramic chip 0.01 µ F/50V
C920 963 9004 711 Ceramic chip 0.1 µ F/50V
C921 963 9004 698 Ceramic chip 0.01 µ F/50V
C923 963 9004 711 Ceramic chip 0.1 µ F/50V
C925 963 9004 711 Ceramic chip 0.1 µ F/50V
C926 Electrolytic 10 µ F/35V
C931 963 9004 698 Ceramic chip 0.01 µ F/50V
C936 963 9004 711 Ceramic chip 0.1 µ F/50V
C937 Electrolytic 10 µ F/35V
C938 Electrolytic 1 µ F/50V
C939,940 963 9004 698 Ceramic chip 0.01 µ F/50V
C943 Electrolytic 0.1 µ F/50V
C944 963 9004 698 Ceramic chip 0.01 µ F/50V
C946,947 963 9004 711 Ceramic chip 0.1 µ F/50V
C948 Electrolytic 10 µ F/35V
C949 Electrolytic 2.2 µ F/50V
C950 963 9004 711 Ceramic chip 0.1 µ F/50V
C951 Electrolytic 100 µ F/10V
C952,953 963 9004 711 Ceramic chip 0.1 µ F/50V
C954 963 9004 698 Ceramic chip 0.01 µ F/50V
C956 963 9004 685 Ceramic chip 1000pF/50V
C957 963 9004 711 Ceramic chip 0.1 µ F/50V
C958 Electrolytic 100 µ F/10V
Ref. No. Part No. Part Name Remarks Q'ty
OTHER PARTS GROUP
CB801 963 0050 502 Chip emifil 1
CB803~808 963 0050 502 Chip emifil 6
CB828 963 0050 502 Chip emifil 1
CN801,802 963 0085 302 17P connector socket (TUC-P) 2
CN803 963 0085 409 10P connector socket (TUC-P) 1
JACK801 963 0052 500 1P pin jack 1
L801,802 963 0050 803 Inductor 4.7 µ H2
L803 963 0050 900 Inductor 2.2
µ H1
L805,806 963 0050 803 Inductor 4.7 µ H2
L807 963 0050 900 Inductor 2.2
µ H1
XTAL801 960 0180 907 Crystal 12.288MHz 1

Denon AVR-1802 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	115 W
Power output per channel (20-20KHz@8 Ohm)	80 W
AC input voltage	120 V
AC input frequency	60 Hz
Equalizer	Yes
Audio decoders	DTS, Dolby Digital, Dolby Pro Logic II
3D	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	0
Composite video in	5
S-Video inputs quantity	4
Digital audio coaxial in	1
Digital audio optical in	3

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	171 mm
Weight	10900 g
