Denon AVR-1802 Service Manual

40
AVR-1802/882
Ref. No. Part No. Part Name Remarks Q'ty
VOLTAGE P.W.B. ASS'Y
OTHER PARTS GROUP
CN105 963 0059 202 2P connector cord E1,E1H,E1T 1
CN903 963 0058 805 2P connector cord E1,E1H,E1T 1
CP901 963 0061 203 5P connector base E1,E1H,E1T 1
CP902 963 0059 309 3P connector cord E1,E1H,E1T 1
F101 960 0142 602 Fuse 2.5A E1,E1H,E1T 1
F101A,B 960 0005 804 Fuse clip E1,E1H,E1T 2
F102 963 0044 709 Fuse 3.15A E1,E1H,E1T 1
F102A,B 960 0005 804 Fuse clip E1,E1H,E1T 2
F901 963 0057 107 Fuse 6.3A E1,E1H,E1T 1
F901A,B 960 0005 804 Fuse clip E1,E1H,E1T 2
JK911 960 0143 203 AC outlet E1,E1H,E1T 1
JK912 963 0056 904 SLIDE SW E1,E1H,E1T 1

Denon AVR-1802 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	115 W
Power output per channel (20-20KHz@8 Ohm)	80 W
AC input voltage	120 V
AC input frequency	60 Hz
Equalizer	Yes
Audio decoders	DTS, Dolby Digital, Dolby Pro Logic II
3D	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	0
Composite video in	5
S-Video inputs quantity	4
Digital audio coaxial in	1
Digital audio optical in	3

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	171 mm
Weight	10900 g
