AVR-1802/882
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
R719L,R 963 9004 258 Carbon chip 240 ohm 1/10W
R720L,R 963 9004 148 Carbon chip 130 kohm 1/16W
R721L,R 963 9004 106 Carbon chip 11 kohm 1/10W
R722L,R 963 9003 385 Carbon chip 100 ohm 1/16W
R725L,R 963 9003 385 Carbon chip 100 ohm 1/16W
R726L,R 963 9004 083 Carbon chip 100 kohm 1/16W
R728L,R 963 9004 300 Carbon chip 39 kohm 1/16W
R729L,R 963 9003 385 Carbon chip 100 ohm 1/16W
R730L,R 963 9004 083 Carbon chip 100 kohm 1/16W
R731L,R 963 9004 300 Carbon chip 39 kohm 1/16W
R732L,R 963 9004 300 Carbon chip 39 kohm 1/16W
R737L,R 963 9004 193 Carbon chip 22 ohm 1/16W
R751L,R 963 9004 083 Carbon chip 100 kohm 1/16W
VR101~105 960 0091 601 Semi fixed resistor 1 kohm
CAPACITORS GROUP
C101C Electrolytic 47 µ F/50V
C101FL,FR Electrolytic 47 µ F/50V
C101SL,SR Electrolytic 47 µ F/50V
C102C Electrolytic 10 µ F/50V
C102FL,FR Electrolytic 10 µ F/50V
C102SL,SR Electrolytic 10 µ F/50V
C103C 963 9003 084 Ceramic 100pF/500V
C103FL,FR 963 9003 084 Ceramic 100pF/500V
C103SL,SR 963 9003 084 Ceramic 100pF/500V
C104C 963 9003 084 Ceramic 100pF/500V
C104FL,FR 963 9003 084 Ceramic 100pF/500V
C104SL,SR 963 9003 084 Ceramic 100pF/500V
C105C 960 9003 108 Ceramic 0.022 µ F/25V
C105FL,FR 960 9003 108 Ceramic 0.022 µ F/25V
C105SL,SR 960 9003 108 Ceramic 0.022 µ F/25V
C107C 963 9003 097 Mylar film 0.1 µ F/250V
C107FL,FR 963 9003 097 Mylar film 0.1 µ F/250V
C107SL,SR 963 9003 097 Mylar film 0.1 µ F/250V
C131~135 963 9003 097 Mylar film 0.1 µ F/250V
C136,137 963 0087 203 Electrolytic 10000 µ F/63V
C138 Electrolytic 1 µ F/50V
C141~143 963 0021 900 Mylar film 0.047 µ F/100V
C144 960 9007 201 Electrolytic 3300 µ F/10V
C145 963 9003 123 Electrolytic 1000 µ F/35V
C146 Electrolytic 1 µ F/50V
C148 Electrolytic 1 µ F/50V
C150~C152 963 0021 900 Mylar film 0.047 µ F/100V
C153 963 0021 104 Electrolytic 6800 µ F/16V
C154 Electrolytic 47 µ F/10V
C155 963 9004 559 Ceramic 0.1 µ F/50V
C157 Electrolytic 1 µ F/50V
C158 963 9003 136 Electrolytic 1000 µ F/25V
C159 Electrolytic 1 µ F/50V
C161 Electrolytic 10 µ F/35V
C171 Electrolytic 100 µ F/10V
C171A~C 963 9004 818 Ceramic 0.1 µ F/50V
C172,173 Electrolytic 220
µ F/6.3V
C174 Electrolytic 10
µ F/35V
C175 Electrolytic 4.7 µ F/50V
C176,177 Electrolytic 1 µ F/50V
C178 963 9003 149 Electrolytic 330
µ F/63V
C181 960 0177 208 Ceramic 0.047 µ F/250V(AC)
C182 Electrolytic 10
µ F/100V
C251,252 963 9004 698 Ceramic chip 0.01 µ F/50V
C709L,R Electrolytic 10
µ F/35V
C710L,R 963 9004 685 Ceramic chip 1000pF/50V
C711L,R Electrolytic 220
µ F/6.3V
C712L,R 963 9004 779 Mylar film 0.024 µ F/50V
C713L,R 960 9008 695 Mylar film 0.0068 µ F/100V
C714L,R Electrolytic 4.7 µ F/50V
C715L,R 963 9004 737 Ceramic chip 0.022 µ F/25V
C716L,R Electrolytic 10 µ F/35V
C717L,R 963 9004 601 Ceramic chip 220pF/50V
C718L,R Electrolytic 47 µ F/10V
C719L,R Electrolytic 1 µ F/50V
C720L,R 963 9003 152 Mylar film 0.068 µ F/100V
C721L,R 963 9003 152 Mylar film 0.068 µ F/100V
C723L,R Electrolytic 10 µ F/35V
C724L,R 963 9004 698 Ceramic chip 0.01 µ F/50V
C725,726 963 9004 698 Ceramic chip 0.01 µ F/50V
C727,728 Electrolytic 10 µ F/35V
OTHER PARTS GROUP Q'ty
CN201 963 0085 506 9P connector socket (TUC-P) 1
CN202 963 0085 603 5P connector socket (TUC-P) 1
CN203 963 0085 700 6P connector socket (TUC-P) 1
CN701 963 0086 602 12P connector socket (TUC-P) 1
CN702 963 0086 709 11P connector socket (TUC-P) 1
CN704 963 0086 505 7P connector socket (TUC-P) 1
CP101 960 0197 505 2P connector base 1
CP102 960 0123 304 2P connector base 1
CP103 960 0128 901 3P connector base 1
CP104 960 0128 804 6P connector base 1
CP106 960 0123 207 3P connector base 1
CP501 963 0086 806 9P connector base (TUC-P) 1
CP502~504 963 0086 903 5P connector base (TUC-P) 4
CP505 963 0087 009 6P connector base (TUC-P) 1
CP553 963 0087 106 20P connector base (TUC-P) 1
CP901 963 0048 909 3P connector base 1
F101,102 960 0188 705 Fuse 8A E3 2
