30
AVR-1802/882
Ref. No. Part No. Part Name Remarks
F101 960 0142 602 Fuse 2.5A E2 1
F102 960 0044 709 Fuse 3.15A E2,E1C 1
F101A,B 960 0005 804 Fuse clip E3,E2 2
F102A,B 960 0005 804 Fuse clip E3,E2,E1C 2
GND101,102 960 9006 600 Terminal 2
JK103 960 0194 809 2P speaker terminal 1
JK104 960 0187 803 AC outlet(2P) E3 1
L101C 963 0049 005 Inductor 0.5 µ H1
L101FL,FR 963 0049 005 Inductor 0.5 µ H2
L101SL,SR 963 0049 005 Inductor 0.5
µ H2
L701L,R 235 9003 002 FTZ CHOKE COIL E2 2
RLY101~104 960 0181 702 Relay (G5PA-28 24V) 4
RLY105 963 0071 303 Relay (RSB24S 24V) 1
RLY106 960 0181 605 Relay (G5PA-1-8 12V) 1
TP101~105 960 0161 405 3P connector base 5
 Heat sink 1
 Heat sink 1
 960 0185 708 Power trans. (Mini) E3 1
960 0185 711 Power trans. (Mini) E2 1
960 0185 737 Power trans. (Mini) E1,E1H,E1T 1
960 0185 724 Power trans. (Mini) E1C 1
 963 0018 007 Screw (2S 3 × 8 ZNY/BH) 3
 960 0188 608 4P speaker terminal 1
 963 0074 009 8P speaker terminal 1
 960 0188 103 2P pin jack 1
 960 0188 200 4P pin jack 2
 960 0188 307 6P pin jack 1
 963 0066 114 5P connector base 1
 963 0075 600 6P connector base 1
 963 0068 400 Capacitor cover E2 1
Ref. No. Part No. Part Name Remarks Q'ty
PROCESSOR P.W.B. ASS'Y
SEMICONDUCTORS GROUP
IC201 963 0084 303 IC CXP740096-135Q
IC202 963 0057 602 IC TDA7330BD E2
IC203 960 0080 201 IC KIC9164AN
IC204 963 0043 603 IC KIC9482F
IC205~210 960 0174 502 IC NJM2068DD
IC301 960 0180 004 IC LC75721E
IC302 963 0074 504 IC BU2090F
IC803 269 0186 002 IC GP1FA502RZ
RMC301 960 0181 100 IC NJL64H380A
Q201 269 0054 901 Transistor DTC144EK
Q202 963 0045 902 Transistor 2SC2412KT
Q207,208 960 0196 807 Transistor 2SK117Y
Q209 269 0093 904 Transistor DTA144ES
Q210 269 0040 902 Transistor DTC144ES
Q211~213 960 0196 807 Transistor 2SK117Y
Q214 269 0046 906 Transistor DTA114ES
Q215 269 0020 906 Transistor DTC114ES
Q216 269 0046 906 Transistor DTA114ES
Q300,301 269 0055 900 Transistor DTA144EK
Q302~304 269 0054 901 Transistor DTC144EK
Q305 269 0055 900 Transistor DTA144EK
D201 960 0197 000 Diode KDS160
D202 963 0058 407 Diode IN4007
D203 963 0020 309 Diode 1SS133T
D204,205 960 0197 000 Diode KDS160
D206 960 0197 000 Diode KDS160 E2
D207 960 0197 000 Diode KDS160
D210~212 960 0197 000 Diode KDS160
D213 963 0020 309 Diode 1SS133T
D214 963 0058 407 Diode IN4007
D302~304 963 0020 309 Diode 1SS133T
D305~307 960 0197 000 Diode KDS160
ZD201 963 0047 502 Zener diode MTZJ3.3B
ZD301 960 0095 801 Zener diode MTZJ6.8B
ZD302~305 960 0095 607 Zener diode MTZJ5.6B
LED301,302 960 0197 204 LED PI5-RD/HL50RDRF4T
LED304~309 960 0197 204 LED PI5-RD/HL50RDRF4T
RESISTORS GROUP
R202 963 9003 398 Carbon chip 1 kohm 1/16W
R204 963 9004 342 Carbon chip 4.7 kohm 1/16W
R205 963 9004 070 Carbon chip 10 kohm 1/16W
