36
AVR-1802/882
L403 963 0056 409
MW IF COIL RBW07VB-K5025 BLK
1
RELAY551 963 0083 100 Relay (RSB12S DC12V) 1
SW391-399 963 0045 708 Tact switch 9
SW401 963 0056 700 SW,SLIDE 1
SW901 960 0176 209 Push switch E3 1
SW901 963 0056 603 Push switch
E2,E1,E1C,E1H,E1T
1
T401 960 0186 600 MW IF COIL PCFMAF-270 1
T402 960 0007 349 FM DET TRANS 1
T403 960 0007 352 FM DET TRANS 1
T404,405 960 0071 207 MPX filter E2 2
T406 960 0037 607 Antibirdie filter E2 1
X401 960 0187 405 Crystal 7.2 MHz 1
X402 963 0043 302 Resonator CSB456F11 1
960 0184 000 Screw bracket 2
963 0054 003 Shield tuner pack 1
Plate 1
963 0052 403 3P antenna terminal 1
960 0188 307 6P pin jack 1
963 0061 708 Plate 1
963 0057 000 1P pin jack 1
960 0188 200 4P pin jack 1
960 0188 404 3P pin jack 2
Heat sink 1
963 0018 007 Screw (2S 3
×
8 ZNY/BH) 1
960 0181 304 3P S terminal 1
960 0181 401 4P S terminal 2
960 0188 200 4P pin jack 1
960 0187 502 Head phone jack (D6.5) 1
Wire clamp 2
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks
PRE-AMP P.W.B. ASS'Y
SEMICONDUCTORS GROUP
Q501C 960 0196 603 Transistor KTC2874B
Q501FL,FR 960 0196 603 Transistor KTC2874B
Q501M 960 0196 603 Transistor KTC2874B
Q501SL,SR 960 0196 603 Transistor KTC2874B
Q502C 960 0196 205 Transistor KSA992F
Q502FL,FR 960 0196 205 Transistor KSA992F
Q502M,503M
960 0196 603 Transistor KTC2874B
Q502SL,SR 960 0196 205 Transistor KSA992F
Q503C 960 0196 205 Transistor KSA992F
Q503FL,FR 960 0196 205 Transistor KSA992F
Q503SL,SR 960 0196 205 Transistor KSA992F
Q504C 960 0196 506 Transistor KSC1845F
Q504FL,FR 960 0196 506 Transistor KSC1845F
Q504SL,SR 960 0196 506 Transistor KSC1845F
RESISTORS GROUP
R509C 960 9005 902 Metal film 1.2 kohm 1/4W
R509FL,FR 960 9005 902 Metal film 1.2 kohm 1/4W
R509SL,SR 960 9005 902 Metal film 1.2 kohm 1/4W
R511C 960 9004 301 Metal film 47 ohm 1/4W
R511FL,FR 960 9004 301 Metal film 47 ohm 1/4W
R511SL,SR 960 9004 301 Metal film 47 ohm 1/4W
CAPACITORS GROUP
C501C Electrolytic 22
µ
F/16V
C501FL,FR Electrolytic 22
µ
F/16V
C501M Electrolytic 10
µ
F/35V
C501SL,SR Electrolytic 22
µ
F/16V
C502C Electrolytic 10
µ
F/35V
C502FL,FR Electrolytic 10
µ
F/35V
C502SL,SR Electrolytic 10
µ
F/35V
C503C 963 9003 165 Ceramic 220pF/500V
C503FL,FR 963 9003 165 Ceramic 220pF/500V
C503SL,SR 963 9003 165 Ceramic 220pF/500V
C504C 963 9003 178 Ceramic 220pF/50V
C504FL,FR 963 9003 178 Ceramic 220pF/50V
C504SL,SR 963 9003 178 Ceramic 220pF/50V
C505C 963 9003 181 Ceramic 33pF/500V
C505FL,FR 963 9003 181 Ceramic 33pF/500V
C505SL,SR 963 9003 181 Ceramic 33pF/500V
C506C Electrolytic 100
µ
F/10V
C506FL,FR Electrolytic 100
µ
F/10V
C506SL,SR Electrolytic 100
µ
F/10V
C507C 963 9003 194 Mylar film 0.0022
µ
F/100V
C507FL,FR 963 9003 194 Mylar film 0.0022
µ
F/100V
C507SL,SR 963 9003 194 Mylar film 0.0022
µ
F/100V
C514C Electrolytic 22
µ
F/16V
C514FL,FR Electrolytic 22
µ
F/16V
